Advanced Fiber Materials, Volume. 6, Issue 2, 00367(2024)

A Novel NASICON-Type Na3.5MnCr0.5Ti0.5(PO4)3 Nanofiber with Multi-electron Reaction for High-Performance Sodium-Ion Batteries

Ting Zhu1, Wei Liu1, Xiaobin Liao3, Mengyao Wang3, Hao Fan3, Zihe Wei3, Congcong Cai3, Liyan Yang1, Mufang Li1, Dong Wang1、*, Ping Hu2,3,5、**, and Xuanpeng Wang4,5
Author Affiliations
  • 1Key Laboratory of Textile Fiber and Products, Ministry of Education, Hubei International Scientific and Technological Cooperation Base of Intelligent Textile, Materials & Application, Wuhan Textile University, Wuhan 430200, China
  • 2Hubei Key Laboratory of Micro-Nanoelectronic Materials and Devices, School of Microelectronics, Hubei University, Wuhan 430062, China
  • 3State Key Laboratory of Advanced Technology for Materials Synthesis and Processing, Wuhan University of Technology, Wuhan 430070, China
  • 4Department of Physical Science & Technology, School of Science, Wuhan University of Technology, Wuhan 430070, China
  • 5Hubei Longzhong Laboratory, Wuhan University of Technology (Xiangyang Demonstration Zone), Xiangyang 441000, China
  • show less

    Sodium superionic conductors (NASICONs) show significant promise for application in the development of cathodes for sodium-ion batteries (SIBs). However, it remains a major challenge to develop the desired multi-electron reaction cathode with a high specific capacity and energy density. Herein, we report a novel NASICON-type Na3.5MnCr0.5Ti0.5(PO4)3 cathode obtained by combining electrospinning and stepwise sintering processes. This cathode exhibits a high discharge capacity of 160.4 mAh g-1 and operates at a considerable medium voltage of 3.2 V. The Na3.5MnCr0.5Ti0.5(PO4)3 cathode undergoes a multi-electron redox reaction involving the Cr3+/4+ (4.40/4.31 V vs. Na/Na+), Mn3+/4+ (4.18/4.03 V), Mn2+/3+ (3.74/3.41 V), and Ti3+/4+ (2.04/2.14 V) redox couples. This redox reaction enables a three-electron transfer during the Na+ intercalation/de-intercalation processes. As a result, the Na3.5MnCr0.5Ti0.5(PO4)3 demonstrates a significant enhancement in energy density, surpassing other recently reported SIB cathodes. The highly reversible structure evolution and small volume changes during cycling were demonstrated with in-situ X-ray diffraction, ensuring outstanding cyclability with 77% capacity retention after 500 cycles. Furthermore, a NMCTP@C//Sb@C full battery was fabricated, which delivered a high energy density of 421 Wh kg-1 and exhibited good cyclability with 75.7% capacity retention after 100 cycles. The rational design of composition regulation with multi-metal ion substitution holds the potential to unlock new possibilities in achieving high-performance SIBs. A novel NASICON-structured Na3.5MnCr0.5Ti0.5(PO4)3 nanofiber was successfully designed and prepared. This nanofiber was employed to research the multi-electron reaction and the resulting structural evolution in SIBs. The optimal Na-migration pathway has also been investigated by DFT computations. A full SIB battery was fabricated and delivered a high energy density (421 Wh kg-1) and cyclability (75.7% after 100 cycles at 100 mA g-1).

    Tools

    Get Citation

    Copy Citation Text

    Ting Zhu, Wei Liu, Xiaobin Liao, Mengyao Wang, Hao Fan, Zihe Wei, Congcong Cai, Liyan Yang, Mufang Li, Dong Wang, Ping Hu, Xuanpeng Wang. A Novel NASICON-Type Na3.5MnCr0.5Ti0.5(PO4)3 Nanofiber with Multi-electron Reaction for High-Performance Sodium-Ion Batteries[J]. Advanced Fiber Materials, 2024, 6(2): 00367

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Research Articles

    Received: Sep. 14, 2023

    Accepted: Dec. 26, 2023

    Published Online: Jul. 5, 2024

    The Author Email: Dong Wang (wangdon08@126.com), Ping Hu (huping316@163.com)

    DOI:10.1007/s42765-023-00367-4
