Laser & Optoelectronics Progress, Volume. 61, Issue 12, 1201001(2024)

Simultaneous Retrieval of Ozone Concentration and Aerosol Optical Parameters using Ultraviolet LiDAR

Xiaomin Ma1, Huihui Shan1, Hui Zhang1、*, Kaifa Cao2, Jiajia Han1, Shenhao Wang1, Shaoqing Zhao1, Lingling Huang1, Pengyu Tao1, Changjiang Zhang1, and Zongming Tao1
Author Affiliations
  • 1Department of Basic Sciences, Army Academy of Artillery and Air Defense, Hefei 230031, Anhui, China
  • 2Anhui Kechuang Zhongguang Technology Co., Ltd., Hefei 230037, Anhui, China
  • show less

    Aerosols are the main components of air pollutants, and ozone also has a certain impact on human health. Light detection and ranging (LiDAR) is a powerful tool for detecting the atmosphere. Ozone has a strong absorption in the ultraviolet (UV) band with a wavelength less than 320 nm. Using UV laser (with a wavelength less than 320 nm) to detect aerosols will cause mutual effects between aerosol absorption, ozone absorption, and atmospheric molecular absorption. Consequently, retrieving aerosol optical parameters from the UV LiDAR equation will be more complex than that from the visible LiDAR equation. A dual-wavelength UV LiDAR detection system was designed to obtain UV LiDAR echo signals at two wavelengths. An iterative algorithm was proposed to simultaneously invert the ozone concentration profile and aerosol optical parameter profile from the two LiDAR equations, with ozone concentration profile as the constraint condition. The calibrated three-wavelength UV ozone LiDAR of Anhui Kechuang Zhongguang Technology Co., Ltd., and the dual-wavelength UV LiDAR of our group were used to verify the correctness of the proposed inversion algorithm in the same place at the same time. The ozone concentration profiles retrieved by the two LiDARs were compared and analyzed, with a relative error less than 13%. Based on this, the designed dual-wavelength UV LiDAR detection system was used to detect atmospheric for continuous 10 h. The process involved comparing and analyzing the ozone concentration retrieved near the ground with ozone concentration detected by national control stations. The relative errors of both are less than 17.6%. The results of the two comparative experiments indicate that the proposed inversion algorithm is feasible and reliable.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Xiaomin Ma, Huihui Shan, Hui Zhang, Kaifa Cao, Jiajia Han, Shenhao Wang, Shaoqing Zhao, Lingling Huang, Pengyu Tao, Changjiang Zhang, Zongming Tao. Simultaneous Retrieval of Ozone Concentration and Aerosol Optical Parameters using Ultraviolet LiDAR[J]. Laser & Optoelectronics Progress, 2024, 61(12): 1201001

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Atmospheric Optics and Oceanic Optics

    Received: Aug. 23, 2023

    Accepted: Sep. 18, 2023

    Published Online: Jun. 17, 2024

    The Author Email: Zhang Hui (yhhzhhf@sina.com)

    DOI:10.3788/LOP231964

    CSTR:32186.14.LOP231964
