High Power Laser and Particle Beams, Volume. 36, Issue 2, 025010(2024)

Design and implementation of a miniaturized high voltage power supply for pulse traveling wave tube

Yinchuan Liu, Wenlei Gao, Yafeng Wang, Qihui Liu, and Yinxing Chen
Author Affiliations
  • Beijing Vacuum Electronics Research Institute, Beijing 100015, China
  • show less

    To meet the demand of radar for miniaturization of transmitter, a miniaturized high-voltage power supply is designed for a certain type of TWT. The high voltage power supply adopts a phase shifted full bridge topology structure, and the high voltage rectifier circuit uses SiC diodes to improve the power density of the power supply. The miniaturized pulse high-voltage power supply has been developed, with a cathode voltage of -6.5 kV, a maximum working pulse width of 2 ms, and a peak power of 1600 W. The joint test with traveling-wave tube shows that the output RF power of TWT is stable during pulse operation. The test results verify the feasibility of the design method.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yinchuan Liu, Wenlei Gao, Yafeng Wang, Qihui Liu, Yinxing Chen. Design and implementation of a miniaturized high voltage power supply for pulse traveling wave tube[J]. High Power Laser and Particle Beams, 2024, 36(2): 025010

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jul. 3, 2023

    Accepted: Sep. 4, 2023

    Published Online: Mar. 21, 2024

    The Author Email:

    DOI:10.11884/HPLPB202436.230207
