Chinese Optics, Volume. 17, Issue 5, 1162(2024)

Visible polarized reflection of target material surface based on improved Blinn masking function

Cheng-lin LIU1,2, Jun-tong ZHAN1、*, Su ZHANG1, Chao WANG1, Qiang FU1, Ying-chao LI1, Jin DUAN3, and Hui-lin JIANG1
Author Affiliations
  • 1National and Local Joint Engineering Research Center for Space Optoelectronics Technology, Jilin Key Laboratory of Space Optoelectronics Technology, Changchun University of Science and Technology, Changchun 130022, China
  • 2School of Opto-Electronic Engineering, Changchun University of Science and Technology, Changchun 130022, China
  • 3School of Electronics and Information Engineering, Changchun University of Science and Technology, Changchun 130022, China
  • show less

    Focusing on the visible polarization reflection characteristics of typical target materials surfaces, the polarization bidirectional reflection distribution function model based on the improved Blinn masking function was established considering the effects of specular reflection, diffuse reflection and volume scattering, which maked up for the defect of traditional "V" masking function. The physical parameters of the target materials were inverted by genetic algorithm, and the visible light polarization characteristics of four target materials, namely polypropylene, 99 alumina ceramic, iron and green painted aluminum, were simulated. Experimental tests validate the model’s accuracy. Results indicate that at an incidence angle of 50°, relative azimuth angles of 90°-270°, and detection angles of 0°-60°, the improved model reduces the root mean square error (RMSE) by 70.61% to 24.73%, with a minimum RMSE of 0.0129. Significant polarization is observed at relative azimuth angles of 120°-240°. The larger the ratio of the real part to the imaginary part of the complex refractive index of the four materials, the greater the peak value of the degree of polarization. In the visible light band, the wavelength has little effect on the degree of polarization. These findings provide theoretical data supporting the understanding of polarization characteristics in typical target materials.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Cheng-lin LIU, Jun-tong ZHAN, Su ZHANG, Chao WANG, Qiang FU, Ying-chao LI, Jin DUAN, Hui-lin JIANG. Visible polarized reflection of target material surface based on improved Blinn masking function[J]. Chinese Optics, 2024, 17(5): 1162

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Dec. 3, 2023

    Accepted: --

    Published Online: Dec. 31, 2024

    The Author Email:

    DOI:10.37188/CO.2023-0217
