High Power Laser and Particle Beams, Volume. 36, Issue 8, 083003(2024)

Design and test of an array antenna transmitting high power microwave

Yongyan Mao1, Fan Zhang1,2, Chuan Tian1, Jiangyuan Xie1, and Zhaoxin Jin1
Author Affiliations
  • 1Electronic Engineering Research Institute, Xi'an 710100, China
  • 2School of Electronics and Information, Northwestern Polytechnical University, Xi'an 710072, China
  • show less

    A slotted waveguide array antenna operating at S band for transmitting high power microwave is developed in this paper. The profile height is reduced by arranging the coupling waveguide and feeding waveguide on same layout. The coupling slots with same offsets direction and the radiating slots arranged regularly compensate phase, which achieves in-phase superposition of pattern of slot units. The influence of different slot parameters and types of divider on power capacity of the antenna are simulated. 0.1 MPa SF6 gas is filled in the sealed antenna to enhance power-handling capability. The simulated and test results show that the antenna has a 6.7% bandwidth with VSWR less than 1.5 and a gain up to 27 dBi. Hot test of this antenna is carried out fed by narrow-band high power microwave source. The transmitted waveform and the output one agree well. The measured output power of the source is 2.67 MW.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yongyan Mao, Fan Zhang, Chuan Tian, Jiangyuan Xie, Zhaoxin Jin. Design and test of an array antenna transmitting high power microwave[J]. High Power Laser and Particle Beams, 2024, 36(8): 083003

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Dec. 24, 2023

    Accepted: May. 17, 2024

    Published Online: Aug. 8, 2024

    The Author Email:

    DOI:10.11884/HPLPB202436.230448
