Optics and Precision Engineering, Volume. 33, Issue 9, 1341(2025)

Low signal-to-noise ratio spectral interferometry film thickness measurement based on self-attention neural network

Chen WANG, Zizheng WANG, Zhaoran LIU, Chengyuan YAO, and Chunguang HU*
Author Affiliations
  • State Key Laboratory of Precision Measurement Technology and Instruments, Tianjin University, Tianjin300072, China
  • show less

    To enhance the robustness of film thickness measurements from low signal-to-noise ratio (SNR) spectral data, a measurement approach based on a self-attention neural network (SANN) is developed. While the conventional Fourier transform method effectively measures thickness on high SNR data, its accuracy deteriorates as noise obscures the principal interference frequency under low SNR conditions, hindering precise thickness extraction. This study introduces a self-attention neural network model that takes spectral data as input and outputs film thickness, employing an adaptive attention mechanism to dynamically weight spectral points across different wavelengths, thereby improving analysis of low SNR spectral data. Experimental data were obtained using a spectral interference film thickness measurement system and subsequently augmented through wavelength drift and adaptive intensity normalization strategies to expand the dataset and enhance the model's generalization. Model optimization identified an architecture comprising eight encoder layers and 128 hidden nodes per layer.Using wafer measurements as a case study, evaluation on spectral data containing outliers demonstrated a maximum relative thickness measurement error of 3.62% on the low SNR validation set. These results indicate that the proposed method effectively suppresses noise influence, mitigates outlier deviations common in Fourier transform approaches, and substantially improves measurement stability. the applicability of the proposed method is validated to a broader range of thin film measurement scenarios.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Chen WANG, Zizheng WANG, Zhaoran LIU, Chengyuan YAO, Chunguang HU. Low signal-to-noise ratio spectral interferometry film thickness measurement based on self-attention neural network[J]. Optics and Precision Engineering, 2025, 33(9): 1341

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Mar. 3, 2025

    Accepted: --

    Published Online: Jul. 22, 2025

    The Author Email:

    DOI:10.37188/OPE.20253309.1341
