Chinese Journal of Liquid Crystals and Displays, Volume. 40, Issue 8, 1154(2025)

Two-frame phase-shifting interferometry phase retrieval algorithm based on PSI-IPENet

Shasha XU1,2, Chenglin YANG1,2, Mingxing LI3, Jiuba GE1,2, Jingjing WU1,2, Lin YU1,2, Huaxin ZHU1,2, and Lifa HU1,2、*
Author Affiliations
  • 1College of Science, Jiangnan University, Wuxi 214122, China
  • 2Jiangsu Provincial Research Center of Light Industry Opto-electronic Engineering and Technology, Wuxi 214122, China
  • 3Xi'an Institute of Applied Optics, Xi'an 710018, China
  • show less

    Phase-shifting interferometry is a widely used technique in precision optical metrology. However, conventional PSI methods typically require three or more phase-shifted interferograms, which limits their applicability in dynamic measurements and vibration-sensitive environments. To address this issue, this paper proposes a deep learning-based framework named PSI-IPENet. The framework adopts a Two-to-One structure, where two phase-shifted interferograms are used as dual-channel input, corresponding to a single phase map as the supervisory signal, and a dedicated dataset is constructed for training. PSI-IPENet leverages the feature extraction capability of IPENet and incorporates the physical characteristics of interferometric imaging, thereby enhancing the robustness and noise resistance of phase retrieval. Experimental results demonstrate that the proposed method maintains high-precision phase recovery performance even with a low number of input frames. Compared with the traditional four-step phase-shifting method, it shows significant advantages in terms of signal-to-noise ratio and phase error metrics.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Shasha XU, Chenglin YANG, Mingxing LI, Jiuba GE, Jingjing WU, Lin YU, Huaxin ZHU, Lifa HU. Two-frame phase-shifting interferometry phase retrieval algorithm based on PSI-IPENet[J]. Chinese Journal of Liquid Crystals and Displays, 2025, 40(8): 1154

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Apr. 7, 2025

    Accepted: --

    Published Online: Sep. 25, 2025

    The Author Email: Lifa HU (hulifa@jiannan.edu.cn)

    DOI:10.37188/CJLCD.2025-0077
