Laser & Optoelectronics Progress, Volume. 62, Issue 19, 1906018(2025)

Research on Calibration Method of Distributed Fiber Optic Strain Sensor (Invited)

Xinwei Chen1,2、*, Guyue Pan1,2, Zhou Zheng1,2, and Jihao Zhang1,2
Author Affiliations
  • 1Optoelectronic Transmission Sensing Department of the Eighth Research Institute of China Electronics Technology Group Corporation, Hefei 230041, Anhui , China
  • 2Anhui Fiber Optic Sensing Engineering Laboratory, Hefei 230041, Anhui , China
  • show less

    A calibration method for strain based on microwave true time delay is proposed for distributed optical fiber strain sensors. When a segment of the sensing fiber is subjected to strain, causing a change in the fiber's time delay, the phase of the microwave signal transmitted through the sensing fiber will correspondingly change. Based on this principle, a microwave signal is confined to propagate within the sensing fiber using a microwave photonic link. The phase change of this microwave signal is measured using a vector network analyzer, and the strain applied to the sensing fiber is derived, thereby enabling the calibration of the strain coefficient for the distributed optical fiber strain sensor. This method directly measures the change in fiber time delay to determine the strain value and achieves a measurement time as low as ms level. Experimental results demonstrate that the calibration accuracy of this method is 0.18 (°)/(km·με).

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Xinwei Chen, Guyue Pan, Zhou Zheng, Jihao Zhang. Research on Calibration Method of Distributed Fiber Optic Strain Sensor (Invited)[J]. Laser & Optoelectronics Progress, 2025, 62(19): 1906018

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Fiber Optics and Optical Communications

    Received: Jun. 18, 2025

    Accepted: Jul. 17, 2025

    Published Online: Sep. 30, 2025

    The Author Email: Xinwei Chen (cxw553@tju.edu.cn)

    DOI:10.3788/LOP251483

    CSTR:32186.14.LOP251483
