High Power Laser and Particle Beams, Volume. 36, Issue 3, 033008(2024)

Design and research of C-band miniaturized high power microwave output window

Pengxin Mao, Yongliang Tang, Xiufang Wang*, and Qingxiang Liu
Author Affiliations
  • School of Physical Science and Technology, Southwest Jiaotong University, Chengdu 610031, China
  • show less

    To meet the high power capacity and compact application requirements of microwave output window in high power microwave system, a C-band miniaturized high power microwave output window is designed based on the design theory of traditional box window by optimizing the form structure and adding transition segments. By increasing the surface area of the window and changing the connection mode of the rectangular waveguide-circular waveguide transition segment, the power capacity can be increased and the longitudinal size of the microwave output window can be reduced. The “I” form structure can effectively suppress the influence of multipactor near the triple point(vacuum-media-mental) on the performance of the output window. On the basis of electromagnetic simulation, the multipactor near the triple point of the microwave output window is studied by using the Particle-in-Cell method. From the microscopic point of view, it is further confirmed that the “I” form structure can make the position of the triple point move, reduce the probability of multipactor generated by the electrons emitted by the triple point on the surface of the window, and reduce the breakdown risk of the microwave output window. The design results show that the main mode reflection coefficient of the microwave output window at the center frequency is lower than 0.01, the transmission efficiency is higher than 99.9%, and the power capacity can reach 47.9 MW.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Pengxin Mao, Yongliang Tang, Xiufang Wang, Qingxiang Liu. Design and research of C-band miniaturized high power microwave output window[J]. High Power Laser and Particle Beams, 2024, 36(3): 033008

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Oct. 17, 2023

    Accepted: Jan. 11, 2024

    Published Online: Mar. 20, 2024

    The Author Email: Xiufang Wang (xwang66880@163.com)

    DOI:10.11884/HPLPB202436.230359
