Chinese Optics, Volume. 17, Issue 2, 366(2024)
An XY defocus aberration correction method for high-energy lasers
A method for correcting XY defocus aberrations, based on Hartmann-Shack wavefront sensor and two-dimensional beam-shaping light path, was presented due to the large percentage of defocus and 0° astigmatism aberrations with large PV values in high-energy laser beam. The first step is to derive an expression for XY defocus aberrations by linearly combining the defocus and 0° astigmatism terms of Zernike polynomials. The coefficients directly characterize the wavefront peak-to-valley (PV) values of X and Y defocus. At the same time, compensation for XY defocus wavefronts of the laser beam can be achieved by fine-tuning the mirror spacing in the two-dimensional shaping optics of the high-energy laser. Therefore, the Hartmann wavefront sensor is used to extract the coefficients of XY defocus aberrations from the laser beam. The computer dynamically adjusts the mirror spacing in the two-dimensional shaping optics based on these coefficient values to correct XY defocus aberrations and improve the beam quality of the output laser beam. The results of the experiment showcase a significant decrease in PV value of XY defocus aberrations from 5.2 μm and 1.1 μm to less than 0.5 μm, as well as a decrease in β factor from 3.1 to 1.8, resulting in substantial improvement in beam quality.
Get Citation
Copy Citation Text
Ya-fei FENG, Cheng-fu WEI, Xiao-ming REN, Jian-zeng GUO, Jie WANG. An XY defocus aberration correction method for high-energy lasers[J]. Chinese Optics, 2024, 17(2): 366
Category:
Received: Aug. 20, 2023
Accepted: --
Published Online: Apr. 15, 2024
The Author Email:
