High Power Laser and Particle Beams, Volume. 37, Issue 7, 071003(2025)

Performance characterization and defect analysis of large-aperture sampling optics based on cavity ring-down method

Wenchao Zhou1,2, Ting Deng1,2, Chen Peng1,2, Yulong Cao1,2, Wei Wei1,2, Siliang Liu1,2, and Jing Wang3
Author Affiliations
  • 1Institute of Applied Electronics, CAEP, Mianyang 621900, China
  • 2National Key Laboratory of Science and Technology on Advanced Laser and High Power Microwave, Mianyang 621900, China
  • 3School of Optoelectronic Science and Engineering, University of Electronic Science and Technology of China, Chengdu 610054, China
  • show less

    In high-energy laser systems, the performance parameters of large-aperture sampling optics determine the accuracy of beam testing and evaluation, as well as the precision of overall system performance control. This paper focuses on the performance testing requirements of sampling optics with high-reflectivity (HR) on the front surface and anti-reflectivity (AR) on the back surface. Utilizing the cavity-ring-down (CRD)-based reflectivity uniformity testing of large-aperture sampling optics, the reflectivity distribution, optical loss, and high-resolution scanning imaging of defects of sampling optics are obtained by scanning measuring the incident light from both the reflective film surface and the anti-reflective film surface, respectively. Furthermore, by comparing and analyzing the defect distribution maps, the classification of defects in the reflective film, transmissive film, and substrate of the sampling optics is achieved. Finally, by establishing a dual channel CRD system, the residual reflectance distribution of anti-reflective film and the types of defects in the transmissive film were obtained. The testing and analysis method proposed in this paper provides a systematic and comprehensive characterization tool for the performance evaluation and defect analysis of sampling optics.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Wenchao Zhou, Ting Deng, Chen Peng, Yulong Cao, Wei Wei, Siliang Liu, Jing Wang. Performance characterization and defect analysis of large-aperture sampling optics based on cavity ring-down method[J]. High Power Laser and Particle Beams, 2025, 37(7): 071003

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Dec. 4, 2024

    Accepted: Apr. 1, 2025

    Published Online: Jul. 18, 2025

    The Author Email:

    DOI:10.11884/HPLPB202537.240413
