Acta Optica Sinica, Volume. 45, Issue 16, 1624001(2025)

Reconfigurable Transflective Structural Color Metasurfaces Based on Low-Loss Phase-Change Material Sb₂S₃

Shuo Deng, Qiang He, Xuan Xiong*, and Xiangshui Miao
Author Affiliations
  • School of Integrated Circuits, Huazhong University of Science and Technology, Wuhan 430074, Hubei , China
  • show less

    Objective

    Dynamic reconfigurable metasurfaces represent an advancing frontier in optical and materials science, enabling the modulation of optical properties for applications ranging from smart displays to optical sensing. Traditional methods, however, are predominantly restricted to single mode (reflection or transmission) displays and exhibit significant loss. This paper presents a novel all-dielectric metasurface incorporating low-loss phase change material (PCM) Sb2S3, designed to achieve concurrent high-efficiency reflective and transmissive structural color display in the visible spectrum. The research demonstrates dynamic optical control through reversible phase transitions of Sb2S3, and investigates the applications of such metasurfaces in multifunctional optical devices.

    Methods

    The metasurface architecture comprises TiO2 nanopillars integrated with a Sb2S3 PCM layer at the base, positioned on a transparent quartz substrate. The configuration utilizes Mie resonance effects in dielectric nanostructures to achieve robust light-matter interaction with minimal loss. Critical structural parameters include nanopillar diameter (D), gap between nanopillars (G), and thicknesses of the Sb2S3 layer (tPCM), upper TiO2 layer (tTiO2), and bottom TiO2 reflector (tsub). Through switching Sb2S3 between amorphous (low extinction coefficient) and crystalline (high extinction coefficient) states, the effective refractive index and loss of the metasurface are dynamically modulated, enabling regulation of electric dipole (ED) and magnetic dipole (MD) resonances. Time-domain finite-difference (FDTD) simulations were performed to examine the optical responses, including reflectance, transmittance, and CIE chromaticity coordinates, under varying structural parameters and PCM states.

    Results and Discussions

    The metasurface structure, incorporating TiO2 nanopillars with a Sb2S3 PCM layer at the base (Fig. 1), employs Mie resonance to achieve independent tuning of ED modes through layer thickness adjustment. Increasing tPCM amplifies optical loss in the crystalline state, suppressing ED resonance (positioned at the nanopillar base) more substantially than MD resonance (distributed internally), resulting in stronger attenuation of the ED-related reflection peak (up to 70% intensity decrease) compared to the MD peak during phase transition [Figs. 3(a)?(b)]. Modification of D and G enables full visible spectrum coverage in reflective mode, with reflection peaks redshifting as nanopillar volume increases due to enhanced effective refractive index, and a broad CIE chromaticity gamut (exceeding 70% of CIE 1931 space) in the amorphous state that contracts upon ED suppression in the crystalline state (Fig. 5). In transmissive mode, the metasurface exhibits notch patterns corresponding to reflection peaks with high transmittance (>60%) due to low-loss materials, with minimal PCM impact as the transmission path primarily traverses the nanopillar and substrate, avoiding the PCM base [Fig. 2(d)?(f)]. The PCM’s volume directly affects tuning efficiency: larger tPCM enhances extinction coefficient in the crystalline state, promoting ED suppression and peak redshifting [Figs. 3(a)?(b)]. Furthermore, the metasurface demonstrates high sensitivity to environmental refractive index, with reflection peaks redshifting and colors changing from green to magenta as the refractive index increases from 1.0 to 1.44, enabling visual refractive index sensing (Fig. 6). The low extinction coefficient of amorphous Sb2S3 ensures high energy efficiency (reflectance >70%, transmittance >80%), with crystalline-state absorption primarily affecting ED modes while preserving MD functionality, demonstrating independent resonance control through PCM phase transitions.

    Conclusions

    This investigation presents a reconfigurable transflective structural color metasurface utilizing low-loss PCM Sb2S3, engineered for full-color reflective and transmissive display applications. Through optimization of structural parameters and film thicknesses, the metasurface achieves comprehensive visible spectrum coverage and dynamic optical tuning via independent control of ED resonances through Sb2S3 phase transitions. The architecture incorporates polarization-insensitive cylindrical TiO2 nanopillars with a Sb2S3 PCM layer embedded at the base, adjacent to a TiO2 reflector on a quartz substrate. This configuration optimizes energy efficiency by reducing polarization dependence and utilizing low-loss materials, facilitating simultaneous high reflectance (>70%) and transmittance (>80%) across the visible spectrum. PCM’s strategic positioning at the ED resonance region enables selective suppression of ED modes during crystallization, while MD resonance remains largely unaffected due to internal nanopillar distribution. Computational analyses demonstrate that the upper TiO2 layer primarily modulates MD resonance wavelengths, while the bottom TiO2 layer affects ED resonances. In the amorphous state, pronounced Mie resonances produce vibrant structural colors, whereas crystallization disrupts ED resonances through increased extinction, diminishing reflectance and constraining the color gamut. The tuning efficiency increases with PCM volume, as thicker Sb2S3 layers enhance loss-induced ED suppression. Furthermore, the metasurface exhibits significant sensitivity to environmental refractive index variations, with reflection peaks redshifting and colors changing noticeably across different media, indicating its potential for optical sensing applications. This research introduces an adaptable metasurface design that integrates dual-mode color display, dynamic tunability, and low-loss operation, providing novel perspectives for reconfigurable optical devices in smart displays, optical communications, and adaptive sensing systems.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Shuo Deng, Qiang He, Xuan Xiong, Xiangshui Miao. Reconfigurable Transflective Structural Color Metasurfaces Based on Low-Loss Phase-Change Material Sb₂S₃[J]. Acta Optica Sinica, 2025, 45(16): 1624001

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Optics at Surfaces

    Received: Mar. 25, 2025

    Accepted: May. 26, 2025

    Published Online: Aug. 7, 2025

    The Author Email: Xuan Xiong (2006210136@mail.hust.edu.cn)

    DOI:10.3788/AOS250791

    CSTR:32393.14.AOS250791
