Chinese Journal of Liquid Crystals and Displays, Volume. 39, Issue 8, 1070(2024)

Dehazing stray light algorithm for fundus retinal image

Junshuai GAI1,2, Yuting MA1,2、*, Yunhai ZHANG2, Haomin YANG2, Yulong LIU3, Yun XIAO2,4, and Tongda WEI2,5
Author Affiliations
  • 1College of Electronic and Information Engineering,Changchun University of Science and Technology,Changchun 130000,China
  • 2Jiangsu Key Laboratory of Medical Optics,Suzhou Institute of Biomedical Engineering and Technology,Chinese Academy of Sciences,Suzhou 215163,China
  • 3The Second Affiliated Hospital of Soochow University,Suzhou 215004,China
  • 4Shenyang Guoke Guangming Medical Technology Co. Ltd.,Shenyang 110167,China
  • 5Jinan Guoke Medical Technology Development Co. Ltd.,Jinan 250102,China
  • show less

    This paper addresses the issue of hazy stray light in fundus retinal images, which leads to unclear blood vessel details. The proposed dehazing algorithm for fundus retinal images is based on the dark channel theory and incorporates Gamma transformation. The algorithm enhances the clarity of the image while preserving blood vessel information. This algorithm aims to defog images by processing the R, G and B channels separately. Firstly, the algorithm calculates the dark channel image using adaptive window minimum filtering and takes the average value of the top 0.1% pixels as the atmospheric illumination intensity value. Secondly, the algorithm solves the rough transmittance of the image and improves it using the guided filtering algorithm. Finally, the algorithm restores the haze-free image using the atmospheric scattering model and applies Gamma transformation. The experimental results show that the information entropy and average gradient of the restored image increase by an average of about 6.8% and 11.6%, respectively. The algorithm in this paper can quickly and effectively remove hazy stray light in the fundus retinal image, restore the image to be clear and natural, and retain the details information of retinal blood vessels.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Junshuai GAI, Yuting MA, Yunhai ZHANG, Haomin YANG, Yulong LIU, Yun XIAO, Tongda WEI. Dehazing stray light algorithm for fundus retinal image[J]. Chinese Journal of Liquid Crystals and Displays, 2024, 39(8): 1070

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Image Enhancement

    Received: Sep. 2, 2023

    Accepted: --

    Published Online: Sep. 27, 2024

    The Author Email: Yuting MA (mayt@sibet.ac.cn)

    DOI:10.37188/CJLCD.2023-0289
