Journal of Innovative Optical Health Sciences, Volume. 18, Issue 4, 2544001(2025)

Designing a portable and accessible diffuse reflectance spectroscopy system for real-time detection of cervical intraepithelial neoplasia

Allison Scarbrough, Diana Moses, Tongtong Lu, and Bing Yu*
Author Affiliations
  • Joint Department of Biomedical Engineering, Marquette University and Medical College of Wisconsin, Milwaukee, WI, USA
  • show less

    Significance: Over 80% of cervical cancer cases occur in lower-to-middle income countries (LMIC’s). This is partly because current screening techniques lack affordability, accessibility, and/or reliability for use in LMIC’s. Aim: To develop an optical technique for cervical cancer screening that is affordable, accessible, and reliable for use in LMIC’s. Approach: We developed a portable diffuse reflectance spectroscopy (DRS) system, which costs <$2500 USD to manufacture, and employs a Raspberry Pi to extract the absorption (μa) and reduced scattering (μs) coefficients of biological tissue. The system was subject to travel and intentional rough handling. It was further used to capture 320 DRS spectra taken from 64 tissue-mimicking phantoms. Two users collected phantom data, one “expert”, and one “novice” in biomedical optics. The system was also used to collect 335 spectra from colon, small intestine, and rectal tissue of a fresh ex vivo porcine specimen. A previously described artificial intelligence model was used to extract optical properties, and a GradientBoostingClassifier identified the organ of origin for ex vivo spectra. Results: System alignment was robust to intentional rough handling and travel. Phantom μa and μs were predicted with average root-mean square error of <10%, regardless of user. Regarding ex vivo data, the system predicted the organ of origin with 80–90% accuracy. Statistical differences between predicted μa were observed in all three organs (p<0.001–0.03), and between μs in two organs (p<0.001–0.07). Conclusions: The DRS system has the potential to be affordable, reliable, and accessible for cervical screening in LMIC’s.

    Tools

    Get Citation

    Copy Citation Text

    Allison Scarbrough, Diana Moses, Tongtong Lu, Bing Yu. Designing a portable and accessible diffuse reflectance spectroscopy system for real-time detection of cervical intraepithelial neoplasia[J]. Journal of Innovative Optical Health Sciences, 2025, 18(4): 2544001

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Research Articles

    Received: Dec. 11, 2024

    Accepted: Jan. 31, 2025

    Published Online: Jun. 18, 2025

    The Author Email: Bing Yu (bing.yu@marquette.edu)

    DOI:10.1142/S1793545825440018
