Chinese Journal of Liquid Crystals and Displays, Volume. 39, Issue 3, 257(2024)

4D printed programmable deformable liquid metal-liquid crystal elastomer soft actuator

Faxin WANG1, Huan ZHANG1, Yuanhao CHEN1, Le YANG1, Ran BI1, Yongtao SHEN1, Wei FENG1, and Ling WANG1,2、*
Author Affiliations
  • 1School of Materials Science and Engineering, Tianjin University, Tianjin 300350, China
  • 2Binhai Industrial Research Institute, Tianjin University, Tianjin 300452, China
  • show less

    To obtain liquid crystal elastomer with shape-programmable ability and improve its application potential in soft actuators and soft robots, this work reports a light driven soft actuator based on liquid metal (LM)-liquid crystal elastomer (LCE). The soft actuator is fabricated by 4D printing technology, which endows the actuator robust shape-programmable capability.LM was dispersed in ethanol by sonication, then LM micro-particles were mixed into the liquid crystal solution to obtain uniform LM-LCE ink. Using 4D printing technique, the soft actuator with specific deformation was eventually obtained by further programming the orientation of ink. The alternating orthogonal and conical array LM-LCE soft actuators were created via 4D printing. The actuator has good photothermal performance, when exposed to 808 nm infrared laser, its surface temperature can reach above 120 °C in about 10 s. According to the superior photothermal performance, the alternating orthogonal structure actuator is capable of producing bending deformation quickly, while the conical array structure actuator can produce a convex deformation with the spiral center as the vertex.Based on 4D printing technology, the LM-LCE light-driven soft actuator has robust shape-programmable capability, demonstrating better adaptability and adjustability in dynamic and complex environments, and is anticipated to be extensively used in the fields of medical treatment, military, and soft robot.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Faxin WANG, Huan ZHANG, Yuanhao CHEN, Le YANG, Ran BI, Yongtao SHEN, Wei FENG, Ling WANG. 4D printed programmable deformable liquid metal-liquid crystal elastomer soft actuator[J]. Chinese Journal of Liquid Crystals and Displays, 2024, 39(3): 257

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Research Articles

    Received: Jul. 13, 2023

    Accepted: --

    Published Online: Apr. 29, 2024

    The Author Email: Ling WANG (lwang17@tju.edu.cn)

    DOI:10.37188/CJLCD.2023-0243
