Optical Instruments, Volume. 46, Issue 6, 82(2024)

The effect of link noise correction method based on weighted average of noise in the fiber optic temperature delay ripple

Xiaoyi LI1、*, Qizeng LI2, Yaozong ZHANG1, and Xing CUI1
Author Affiliations
  • 1China North Vehicle Research Institute, Beijing 100071, China
  • 2Tianjin Institute of Advanced Technology, Tianjin 300459, China
  • show less

    The signal transmission delay of the optical fiber time-frequency transfer link fluctuates with the change of temperature, and its fluctuation amplitude increases with the increase of optical fiber link length and temperature change range. For noise with reciprocating fluctuation characteristics in time-frequency transfer links, the weighted average method of the total noise of inter-station clock difference of remote atomic clocks shows good calibration effect in satellite systems. The amplitude of temperature delay fluctuations in ultra-long distance optical fiber time-frequency transfer links far exceeds that of the space-ground communication link of satellite system. The calibration effect of this method on the reciprocating fluctuation noise at the level of optical fiber temperature delay fluctuation is still uncertain. The simulation results based on the hydrogen atomic clock show that this method has good calibration effect on the temperature delay fluctuation of optical fiber. Under the simulated temperature delay fluctuation of 1,000 kilometers, when the time keeping stations at both ends of the optical fiber have 12 hydrogen atomic clocks each, the calibration residual is around 1ns. The difference in frequency stability between the cross-station clock after calibration and the atomic clock is two orders of magnitude lower than the frequency stability of the atomic clock.When the time keeping stations at both ends of the optical fiber have 400 cesium atomic clocks each, the calibration residual is around 10ns. Due to the significant difference in noise between hydrogen atomic clocks and cesium atomic clocks, it’s difficult to achieve joint calculation of hydrogen and cesium atomic clocks.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Xiaoyi LI, Qizeng LI, Yaozong ZHANG, Xing CUI. The effect of link noise correction method based on weighted average of noise in the fiber optic temperature delay ripple[J]. Optical Instruments, 2024, 46(6): 82

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Oct. 17, 2024

    Accepted: --

    Published Online: Jan. 21, 2025

    The Author Email: LI Xiaoyi (409668744@qq.com)

    DOI:10.3969/j.issn.1005-5630.202410170094
