Chinese Optics Letters, Volume. 23, Issue 8, 081201(2025)

Superresolution measurement of thermo-optic coefficient of KTP crystals based on phase amplification

Wuzhen Li1...2,3, Zhiyuan Zhou1,2,3,*, Guangcan Guo1,2,3, and Baosen Shi1,23,** |Show fewer author(s)
Author Affiliations
  • 1CAS Key Laboratory of Quantum Information, University of Science and Technology of China, Hefei 230026, China
  • 2CAS Center for Excellence in Quantum Information and Quantum Physics, University of Science and Technology of China, Hefei 230026, China
  • 3Hefei National Laboratory, University of Science and Technology of China, Hefei 230088, China
  • show less

    In this work, we achieve a fourfold enhancement in thermo-optic coefficient measurement resolution for KTiOPO4 crystal using a self-stabilized birefringence interferometer integrated with cascaded second-harmonic generation. We observe the tunable interference beating phenomenon by rotating a birefringent crystal versus the temperature of the crystal. Furthermore, the fourth-harmonic interference fringes beat 4 times faster than the fundamental wave interference fringes. This beating effect is used to determine the thermo-optic coefficients of the two principal refractive axes with a single measurement. This work provides a feasible, real-time, and robust method for superresolution measurements based on birefringence interferometry.

    Keywords

    1. Introduction

    The thermo-optic coefficient, a critical parameter dictating the temperature-dependent refractive index variation in birefringent crystals such as KTiOPO4 (KTP), LiNbO3 (LN), and BaB2O4 (BBO), plays a pivotal role in optimizing photonic devices, including electro-optic modulators[1], nonlinear frequency conversion[2], and quantum light sources[3]. Accurate measurement of the thermo-optic coefficient is essential for optimizing the design and functionality of these devices under varying thermal conditions. Optical interferometry has been widely used to measure such crystal coefficients due to its noninvasive nature, high precision, and rapid response capability[47]. For example, Pignatiello et al. developed a dual-interferometer system combining Mach–Zehnder and moiré interferometry to simultaneously determine both the thermo-optic coefficients and thermal expansion coefficients of LN and KTP crystals[8]. In addition, Rocha et al. used a dispersive white-light Michelson interferometer to achieve precise measurement of the thermo-optical coefficients of fused quartz and borosilicate over a wide visible spectrum[9]. However, traditional interferometric measurement methods, limited by their phase resolution, typically require measuring the thermo-optic coefficient of materials over a relatively wide temperature tuning range. Especially for thin materials, a large temperature variation will not only significantly increase thermal noise but also exacerbate the measurement errors caused by the thermal expansion effects, and even potentially cause thermal damage to the material. To address these challenges, the phase amplification method is undoubtedly a powerful tool for achieving superresolution measurements of phase variations.

    One well-known method that is used in quantum optics to realize phase amplification is based on the multiphoton number and path entangled state known as the NOON state[1012], which utilizes all N photons passing through either arm of the interferometer to accelerate the phase oscillation of the interferometer, consequently attaining superresolution. Subsequently, Zhou et al. utilized a two-photon interferometer to achieve superresolution measurement of the thermo-optic coefficient of KTP crystal and revealed the interference behavior of photons in a birefringent interferometer[13]. However, it is very difficult to prepare NOON states with high photon numbers; the highest number of the NOON states prepared to date is around 10[14]. Additionally, the detection probability is very low when N is large, and a high-photon-number NOON state is highly sensitive to any optical losses experienced by the photons[15,16]. In addition, in quantum precision measurement, squeezed state injection linear interferometers[17] or nonlinear interferometers[18] based on parametric amplification processes are often used to achieve phase supersensitivity that breaks through the shot noise limit. However, these methods also have limitations in measurement stability and real-time performance. Recently, we reported a phase amplification method based on cascaded second-harmonic generation (SHG) processes to achieve real-time phase superresolution measurement, which has stronger robustness than the NOON state-based method[19]. Therefore, achieving superresolution measurement of the thermo-optic coefficient of birefringent crystals through this phase method is also a subject of significant interest among researchers.

    In this work, we first give a theoretical description of a birefringent Mach–Zehnder interferometer (MZI) based on phase amplification and then achieve superresolution measurement of the thermo-optic coefficient of KTP crystal through a specially designed intrinsically stable birefringent polarization MZI and two polarization-independent SHG modules. After cascaded SHG processes, the oscillation period of the interference curve is reduced to 1/4 of the original, which means that the measurement resolution is improved by 4 times. In addition, the interference-beating phenomenon versus crystal temperature is observed for the fundamental wave (FW), second-harmonic (SH), and fourth-harmonic (FH). The beating intensity can be tuned by rotating the crystal, and the FH interference fringes beat 4 times faster than the FW interference fringes. This beating effect is used to determine the thermo-optic coefficients of the two principal refractive axes with a single measurement. This work overcomes the resolution limitations of traditional interferometry methods and provides a universal framework for characterizing complex thermo-optic behaviors in birefringent crystals.

    2. Methods

    The general theoretical models is given first. Figure 1 shows a graphical summary of the main concept of this work. As shown in Fig. 1(a), an x-cut birefringent KTP crystal is inserted into one arm of the MZI, and the y axis and z axis of the KTP crystal are in the vertical and horizontal directions, respectively. The vertically polarized FW is split into two beams by the beam splitter (BS). The beam of path 1 passes through the KTP crystal and interferes with the beam of path 2 at the output port of another BS.

    Schematic diagram of superresolution interferometry principle. (a) Birefringence MZI. (b) Nonlinear birefringence MZI including SHG process. (c) Birefringence MZI with KTP crystal rotation angle δ. (d) Nonlinear birefringence MZI with KTP crystal rotation angle δ. The interference curve on the right side of the interferometer represents a simplified simulation schematic based on the KTP crystal parameters from Ref. [13] at the wavelength of 1550 nm.

    Figure 1.Schematic diagram of superresolution interferometry principle. (a) Birefringence MZI. (b) Nonlinear birefringence MZI including SHG process. (c) Birefringence MZI with KTP crystal rotation angle δ. (d) Nonlinear birefringence MZI with KTP crystal rotation angle δ. The interference curve on the right side of the interferometer represents a simplified simulation schematic based on the KTP crystal parameters from Ref. [13] at the wavelength of 1550 nm.

    In wave optics, the light field at the output port of the MZI can be expressed as EFW(ω)=E1(ω)eV+eiΔΦ(ω)E2(ω)eV,where E1(ω) and E2(ω) represent the two superimposed light fields from path 1 and path 2 at BS2, and eV and eH represent the unit vectors in the two orthogonal polarization directions, respectively. ΔΦ(ω)=2π[ny(λ0,T)1]L/λ0 represents the phase difference between the two superimposed light fields, where L is the length of the KTP crystal and ny(λ0,T) represents the y-axis refractive index of the KTP crystal related to the fundamental wavelength λ0 and temperature T. ny(λ0,T) can be further expanded as Tdny(λ0,T)/dT+ny(λ0,T0), where dny(λ0,T)/dT denotes the thermo-optical coefficient of the y axis of the KTP crystal. In the following theoretical derivation, it is assumed that E1(ω)=E2(ω), the interference intensity of the FW can be expressed as IFW(ω)=2I1(ω)[1+cos(2πLTλ0dnydT+φ0)].

    Therefore, by continuously tuning the temperature of the KTP crystal, the thermo-optic coefficient of the y axis can be derived from the period of the resulting cosine interference fringes. As reported in our previous work[19], when we insert SHG modules into the two arms of the MZI, as shown in Fig. 1(b), the oscillation speed of the SH interference fringes will be twice as fast as that of the FW, and the corresponding complex amplitude and intensity of the SH interference light field can be expressed as ESH(2ω)=E1(2ω)eV+ei2ΔΦ(ω)+iΔΦ(2ω)E2(2ω)eV,ISH(2ω)=2I1(2ω){1+cos[4πLTλ0dnydT+2φ0+ΔΦ(2ω)]},where E1(2ω) and E2(2ω) are the two superimposed SH light fields at the output port of the BS, and the relationships between the SHG beam and the two FW beams are given by E1(2ω)E1(ω)tanh[κE1(ω)] and E2(2ω)E2(ω)tanh[κE2(ω)], respectively; κ is a constant that is proportional to the second-order susceptibility χ(2) and other experimental parameters of the nonlinear crystal used here. ΔΦ(2ω) is the phase difference generated by the SH beams of the two arms of the interferometer during propagation. From Eqs. (1), (2), and (3), we can see that after phase amplification, the equivalent thermo-optic coefficient of the y axis is increased to twice its original value, which means that the interferometer can more easily distinguish the thermo-optic coefficient of the crystal within a limited temperature tuning range. In addition, this superresolution capability can be further enhanced by cascading more SHG modules in the two arms of the MZI.

    Next, we rotate the KTP crystal in the birefringence MZI around the x axis (the direction of beam propagation), as shown in Fig. 1(c). The corresponding complex amplitude and intensity of the FW interference light field can be expressed as EFW(ω,δ)=E1(ω)eV+E2(ω)(αeH+βeV),IFW(ω,δ)=I1(ω)[1+sin4δ+cos4δ+2cos2δsin2δcos(ΔφyΔφz)+2cos2δcos  Δφy+2sin2δcosΔφz],where |α|2+|β|2=1, α=cosδsinδ(eiΔφzeiΔφy), β=cos2δeiΔφy+sin2δeiΔφz=|β|eiθ, δ is the rotation angle of the KTP crystal, and Δφi=2πni(λ0,T)L/λ0(i=y,z) represents the optical phase change of the light-field propagating along the y axis and z axis of the birefringent crystal. It should be noted that IFW(ω,δ) in Eq. (4) has ignored the background noise generated by the horizontal polarization component in EFW(ω). According to Eq. (4), it can be seen that the FW interference fringes are no longer single-frequency oscillation curves with uniform amplitude but instead exhibit a beat oscillation curve with amplitude modulated periodically. Furthermore, utilizing this beat frequency effect, we can determine the thermo-optic coefficients of the two principal refractive axes with a single measurement. Subsequently, we analyze the beat frequency effect during phase amplification. Similarly, we rotate the KTP crystal in the nonlinear MZI containing the SHG module by an angle δ, as shown in Fig. 1(d), and the complex amplitude of the interference light field at the BS output port is given by ESH(2ω,δ)=E1(2ω)eV+ei2θE2(2ω)eV.

    The two SH superposition light fields can be given by E1(2ω)E1(ω)tanh[κE1(ω)] and E2(2ω)|β|E2(ω)tanh[κ|β|E2(ω)], respectively. Therefore, the SH interference light-field intensity can be expanded as ISH(2ω,δ)I1(ω){tanh2[κE1(ω)]+|β|2tanh2[κ|β|E2(ω)]+2|β|tanh[κE1(ω)]tanh[κ|β|E2(ω)]cos2θ},|β|=sin4δ+cos4δ+2cos2δsin2δcos(ΔφyΔφz),θ=tan1(sin2δsinΔφz+cos2δsinΔφysin2δcosΔφz+cos2δcosΔφy).

    Comparison of Eq. (4) with Eqs. (5) and (6) demonstrate that the interference curve of the SH also exhibits beating behavior, and the beating curve oscillates twice as fast as that of the FW. Based on the same principle, the complex amplitude of the FH is given by EFH(4ω,δ)=E1(4ω)eV+ei4θE2(4ω)eV,E1(4ω)E1(ω)tanh[κE1(ω)]tanh{κE1(ω)tanh[κE1(ω)]},E2(4ω)|β|E2(ω)tanh[κ|β|E2(ω)]tanh{κ|β|E2(ω)tanh[κ|β|E2(ω)]}.

    After the above theoretical derivation, a complete mathematical model of a birefringence interferometer based on the SHG process to achieve phase superresolution measurement is given. Next, we will further experimentally verify the predictions described in the above theoretical model.

    3. Experimental Setup

    A schematic of the experimental setup is shown in Fig. 2. The light source involved in the experiment is a homemade mode-locked fiber laser with a central wavelength of 1560 nm, a pulse duration of 212 ps, and a repetition frequency of 21.6 MHz. After being amplified by a homemade erbium-doped fiber amplifier, the power of the pulsed light can reach 2 W. The linearly polarized pulsed light is first transformed into a 45°-polarized beam using a half-wave plate (HWP), and then injected into a self-stabilized polarization MZI, which contains two KTP crystals; one KTP crystal is used for the measurements, while the other compensates for the optical path length differences between the two arms of the MZI.

    Experimental setup for superresolution measurement. FC, fiber collimator; HWP, half-wave plate; DHWP, dichroic HWP; PBS, polarizing beam splitter; DPBS, dichroic PBS; KTP, potassium titanyl phosphate crystal; PPLN, periodically poled lithium niobate crystal; BBO, β-barium borate crystal; DM, dichroic mirror; BPF, 390-10 nm bandpass filter; OPM, optical power meter.

    Figure 2.Experimental setup for superresolution measurement. FC, fiber collimator; HWP, half-wave plate; DHWP, dichroic HWP; PBS, polarizing beam splitter; DPBS, dichroic PBS; KTP, potassium titanyl phosphate crystal; PPLN, periodically poled lithium niobate crystal; BBO, β-barium borate crystal; DM, dichroic mirror; BPF, 390-10 nm bandpass filter; OPM, optical power meter.

    The self-stable MZI is based on a tilted Sagnac loop, where the clockwise and counterclockwise beams have a traverse distance of 10 mm. Since light beams in the two arms of the MZI are slightly tilted and in counterpropagating configurations, both light beams have nearly the same sensitivity to environmental turbulence, such as temperature fluctuation and vibrations. Both crystals are x-cut so that the beams propagate along the x axis of the crystal. The two KTP (CASTECH Inc) crystals have dimensions of 5mm×5mm×8mm, and both end faces are antireflection-coated for 1560 nm. The temperature of the KTP1 crystal used for the measurement can be tuned from 9(±0.002)°C to 32(±0.002)°C, while the temperature of KTP2 used for compensation is stabilized at a constant 23(±0.002)°C. Moreover, the KTP1 is mounted on a rotation stage to rotate its position with respect to the vertical polarization direction.

    The orthogonally polarized FW from the two arms of the self-stable MZI enters the first Sagnac-type polarization-independent SHG module, which consists of a dichroic PBS (DPBS), a dichroic half-wave plate (DHWP), and a periodically poled lithium niobate (PPLN, CTL Photonics Inc.) crystal with a length of 25 mm and a poling period of 19.62 µm. The operation temperature of the PPLN crystal is set to 39.4°C to fulfill the quasi-phase-matching condition. The Sagnac loop with a DHWP inserted is used to realize the SHG for both vertical and horizontal polarizations, which was demonstrated in our previous work[19].

    Then, the generated SH is separated from the FW propagation path by a dichroic mirror (DM). The second polarization-independent SHG module is composed of two orthogonally glued β-barium borate (BBO, CASTECH Inc) crystals that satisfy type-I birefringence phase-matching conditions. Each BBO crystal has a thickness of 0.5 mm and a phase-matching angle of 30°. The horizontally and vertically polarized SH can be, respectively, converted into oppositely polarized FH through the corresponding BBO crystals. Therefore, two orthogonally polarized 1560 nm FWs pass through two cascaded SHG modules, successively generating 780 nm SH and 390 nm FH. The 45° polarizer is used to perform projection measurements of two orthogonal polarization states, and the resulting interference fringes are detected and recorded by a power meter (Thorlabs, S142C/S145C). When we need to observe the interference fringes of FW (SH), a mirror is used to separate the FW (SH) beam from the original optical path; otherwise, the mirror is not present in the optical path.

    4. Results and Discussion

    Figure 3 shows the interference fringes of the FW, SH, and FH measured experimentally at different rotation angles of the KTP1 crystal. The x axis represents the temperature of the KTP crystal, and the y axis represents the optical power of the measured interference pattern. The panels on the left (from top to bottom) show the beating curves of the FW for rotation angles of δ=0,π/6,π/3,π/2. The panels on the middle and right represent the corresponding beating curves of the SH and FH, respectively. The solid lines are the fitting curves obtained from the theoretical model described above. The rotation angles of δ=0,π/2 represent cases in which the input light polarization coincides with the y and z optical axes of the birefringent crystal. In these two cases, the periods of the interference curves of the SH and FH are reduced to 1/2 and 1/4 of that of the FW interference curve, respectively, which indicates that higher measurement resolution is achieved after phase amplification. The interference visibility of the interference fringes for the FW, SH, and FH at δ=0 (π/2) is 97.4% (94.3%), 96.6% (96%), and 86.4% (88.3%), respectively. The relatively low interference visibility of the FH is primarily attributed to the elongation of the FH beam spot caused by the walk-off effect during the SHG process in the BBO crystal. This results in incomplete spatial overlap between the horizontally and vertically polarized FH fields. Consequently, the nonoverlapping regions of the light fields contribute to background noise during interference, thereby reducing the visibility of the interference fringes. Based on the interference fringes of the FW, SH, and FH under the condition of δ=0 (π/2), the thermo-optic coefficients of the KTP crystal along the y (z) axis were determined to be 1.062×105/K(1.639×105/K), 1.062×105/K(1.631×105/K), and 1.086×105/K(1.630×105/K), respectively.

    Interference beating versus temperature for the FW, SH, and FH. The panels on the left (from top to bottom) represent the FW cases at rotation angles of δ = 0, π/6, π/3, π/2. The panels on the middle and right represent the corresponding interference results of the SH and FH, respectively. Different offsets in each of the interference fringes come from different initial phases between the two arms of the interferometer.

    Figure 3.Interference beating versus temperature for the FW, SH, and FH. The panels on the left (from top to bottom) represent the FW cases at rotation angles of δ = 0, π/6, π/3, π/2. The panels on the middle and right represent the corresponding interference results of the SH and FH, respectively. Different offsets in each of the interference fringes come from different initial phases between the two arms of the interferometer.

    When the polarization direction of the FW does not coincide with the principal axis of the birefringent crystal, the interference fringes exhibit beating behavior of the optical properties along the two axes, and we can determine the optical properties along both axes from any single measurement of this type of beating curve. For example, when δ=π/3, the thermo-optic coefficients of the y and z axes obtained from the beating curves of FW (SH, FH) were 0.980×105/K(0.955×105/K,1.023×105/K) and 1.593×105/K(1.606×105/K,1.618×105/K), respectively. Another essential feature of the beating curve is that the temperature oscillation periods of the beating curves for the SH and FH are 2 times and 4 times faster than that of the FW, respectively, which demonstrates that superresolution measurement of the thermo-optic coefficients of birefringent crystals can still be achieved under beating conditions. In addition, as the phase amplification factor increases, a higher measurement resolution can be achieved. It should be noted that although the actual environmental temperature fluctuation exceeds 0.002°C (usually around ±0.5°C), the relative phase of the interferometer remains stable throughout the measurement period. This indicates that the self-stabilized polarization MZI exhibits excellent resistance to environmental turbulence.

    Next, we characterize the conversion efficiency of the two polarization-independent SHG modules. In our experiment, the polarization-independent SHG modules exhibit nearly identical conversion efficiency characteristics for both horizontally and vertically polarized input lights. Therefore, we show the power conversion efficiency of the two SHG modules in the case of vertically polarized input. The results are shown in Fig. 4, where the dashed lines are the theoretical fitting curves. The nonlinear efficiency of the first SHG process in the experiment exceeds 30%, while that of the second SHG process is less than 0.1%. This is due to two main factors: first, the pump light intensity entering the second SHG process is significantly reduced after the first SHG process; second, the nonlinear crystal used in the second SHG process is 0.5-mm-thick BBO, which has a much smaller nonlinear coefficient compared to PPLN. In addition, for the SHG process based on the BBO crystal, the walk-off effect also leads to a decrease in conversion efficiency. As presented in our previous work, under optimal experimental conditions (with a high-intensity pump laser and a proper crystal), the power conversion efficiency of SHG can be improved to 80%[20]; therefore, much higher levels of superresolution measurements can be achieved in principle.

    Power conversion efficiency of the (a) first and (b) second polarization-independent SHG modules.

    Figure 4.Power conversion efficiency of the (a) first and (b) second polarization-independent SHG modules.

    5. Conclusion

    In summary, we have achieved superresolution measurement of the thermo-optic coefficient of KTP crystal using birefringence interferometry based on the phase amplification method. Through the carefully designed self-stabilized birefringent MZI and polarization-independent SHG modules, the physical mechanism of superresolution interferometric measurements is revealed in detail. After phase amplification, the FH interference fringes oscillate 4 times faster than those of the FW, which indicates a fourfold enhancement in resolution capability. In addition, the interference beating phenomenon versus the crystal temperature has been observed for the FW, SH, and FH. This beating feature is used to determine the optical properties along both crystal axes with a single measurement. Although we have only achieved a fourfold improvement in resolution here, as described in our previous work[19], further optimization of the pump light source and nonlinear crystal parameters, along with the application of optical parametric amplification techniques, can enable even higher measurement resolution. We should point out that the present system is not limited to the determination of the thermo-optic coefficient of a birefringent crystal and can also be used to determine the wavelength dispersion[21] and the electro-optical coefficient of the birefringent crystal. More importantly, compared to methods for achieving superresolution measurements based on the NOON state, our scheme boasts real-time responsiveness and is compatible with existing mature interferometric measurement systems. This work will thus be of great importance for understanding superresolution measurements based on phase amplification.
