Acta Photonica Sinica, Volume. 53, Issue 8, 0812001(2024)

Station Planning Method for Multi-sensor System Collaborative Measurement Field

Xuezhu LIN1,2、*, Dexuan WANG1, Xihong FU3,4, Fan YANG3, Lili GUO1,2, Dongming YAN1, and Lijuan LI1,2
Author Affiliations
  • 1Key Laboratory of Optoelectronic Measurement and Control and Optical Information Transmission Technology, Ministry of Education, College of Optoelectronic Engineering, Changchun University of Science and Technology, Changchun 130022, China
  • 2Zhongshan Institute of Changchun University of Science and Technology,Zhongshan 528437, China
  • 3Xian Institute of Optics and Precision Mechanics, Chinese Academy of Sciences, Xi'an 710119, China
  • 4University of Chinese Academy of Sciences, Beijing 101408, China
  • show less

    With the continuous development and technological advances in the modern industrial field, large component measurement techniques are becoming increasingly important in various fields. Particularly in areas such as large machinery and equipment, aerospace, etc., accurately measuring and evaluating the dimensions and shapes of parts, components, and systems is critical to ensuring product quality, meeting design requirements, and ensuring safety. Among them, station planning plays a key role in large component measurement tasks, and it directly affects the overall accuracy and efficiency of the entire measurement task. Currently, the station planning of large component measurement often relies on experienced surveyors, which leads to an increase in the time and labor cost of the measurement and the instability of the measurement results. Secondly, the traditional method of station planning for large component measurement is often time-consuming and inefficient, lacks theoretical basis and evaluation methods, and is prone to problems such as large number of stations, high number of station transfers and low measurement efficiency, which can not meet the needs of modern manufacturing industry for fast and efficient measurement. In view of the above-mentioned large-scale component multi-sensing system station planning, due to the diversification of system measurement accessibility models and the imbalance of multi-system measurement accuracy, the combined measurement station setting relies heavily on the experience of surveyors and continuous attempts to obtain suitable stations. To solve the problem, this paper proposes a combined measurement station planning method for multi-sensor systems. Firstly, considering the tooling occlusion issue, based on the combined measurement accessibility model in the collaborative measurement field, we establish an initial value solving model for tooling-affected station positions using the Remora optimization algorithm. This model calculates the initial values of measurement stations in the combined measurement system; secondly, addressing the precision constraint issue, we establish a collaborative measurement accuracy model. We formulate an optimization objective function that minimizes the weighted residual values of the observation data and the vector angular measurement errors. We optimize the scaling factor to achieve the best accuracy in station coordinates; finally, a certain target simulator satisfies the position, posture initial assembly and adjustment accuracy requirements are taken as an example. A combined measurement station planning experiment was conducted. The root mean square error of the measurement data after optimization is 0.032 mm. Compared with the measurement planning before optimization, the position measurement accuracy increased by 34%, and the angle measurement accuracy increased by 9.5 %. This method provides improvements in methods for the rapid and precise detection as well as station planning efficiency of components, parts, and systems in large-scale structures. It offers valuable references for further research and applications in the field of measurement.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Xuezhu LIN, Dexuan WANG, Xihong FU, Fan YANG, Lili GUO, Dongming YAN, Lijuan LI. Station Planning Method for Multi-sensor System Collaborative Measurement Field[J]. Acta Photonica Sinica, 2024, 53(8): 0812001

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Instrumentation, Measurement and Metrology

    Received: Dec. 20, 2023

    Accepted: Feb. 27, 2024

    Published Online: Oct. 15, 2024

    The Author Email: LIN Xuezhu (custsnow@163.com)

    DOI:10.3788/gzxb20245308.0812001
