Journal of Innovative Optical Health Sciences, Volume. 18, Issue 1, 2550007(2025)

Multi-bandwidth reconstruction for photoacoustic tomography using cascade U-net

Zezheng Qin1,3、§, Lingyu Ma1,3、§, Zhigang Lei1,3,4, Yiming Ma1,2,3, Weiwei Fu5,6、*, and Mingjian Sun1,2,3、**
Author Affiliations
  • 1School of Astronautics, Harbin Institute of Technology, Harbin 150000, P. R. China
  • 2School of Information Science and Engineering, Harbin Institute of Technology, Weihai 264200, P. R. China
  • 3Harbin Institute of Technology Suzhou Research Institute, Suzhou 215000, P. R. China
  • 4WEGO Holding Co., Ltd., Weihai 264209, P. R. China
  • 5School of Biomedical Engineering (Suzhou), Division of Life Sciences and Medicine University of Science and Technology of China, Hefei, Anhui, P. R. China
  • 6Suzhou Institute of Biomedical Engineering and Technology, Chinese Academy of Science, Suzhou, Jiangsu, P. R. China
  • show less

    Photoacoustic imaging (PAI) employs short laser pulses to excite absorbing materials, producing ultrasonic waves spanning a broad spectrum of frequencies. These ultrasonic waves are captured surrounding the sample and utilized to reconstruct the initial pressure distribution tomographically. Despite the wide spectral range of the laser-generated photoacoustic signal, an individual transducer can only capture a limited segment of the signal due to its constrained bandwidth. Herein, we have developed a multi-bandwidth ring array photoacoustic computed tomography (PACT) system, incorporating a probe with two semi-ring arrays: one for high frequency and the other for low frequency. Utilizing the two semi-ring array PAIs, we have devised a specialized deep learning model, comprising two serially connected U-net architectures, to autonomously generate multi-bandwidth full-view PAIs. Preliminary results from simulations and in vivo experiments illustrate the system’s robust multi-bandwidth imaging capabilities, achieving an excellent PSNR of 34.78 dB and a structural similarity index measure (SSIM) of 0.94 in the high-frequency reconstruction of complex mouse abdominal structures. This innovative PACT system is notable for its capability to seamlessly acquire multi-bandwidth full-view PAIs, thereby advancing the application of PAI technology in the biomedical domain.

    Tools

    Get Citation

    Copy Citation Text

    Zezheng Qin, Lingyu Ma, Zhigang Lei, Yiming Ma, Weiwei Fu, Mingjian Sun. Multi-bandwidth reconstruction for photoacoustic tomography using cascade U-net[J]. Journal of Innovative Optical Health Sciences, 2025, 18(1): 2550007

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Research Articles

    Received: Aug. 21, 2024

    Accepted: Oct. 18, 2024

    Published Online: Feb. 21, 2025

    The Author Email: Fu Weiwei (fuww@sibet.ac.cn), Sun Mingjian (sunmingjian@hit.edu.cn)

    DOI:10.1142/S1793545825500075
