Acta Optica Sinica, Volume. 44, Issue 3, 0316001(2024)
Difference in Extinction Characteristics of Bioparticle Aggregates with Different Monomer Shapes
Biological particle materials have significant wide-band extinction performance, and the monomer shapes of bioparticles are complex with some irregular non-spherical shapes. However, the differences in extinction characteristics of bioparticle aggregates with different monomer shapes are still uncertain and have been ignored in previous research. Thus, we build bioparticle aggregation models with different monomer shapes to calculate the extinction coefficients in the 3-5 μm and 8-14 μm wavebands and analyze the differences in extinction characteristics caused by monomer shapes.
Five typical monomer shapes are constructed by employing multi-sphere models in terms of the scanning electron microscopy (SEM) images, and the complex refractive indices (CRIs) of three biomaterials are calculated according to Kramers-Kronig relations based on specular reflectance in the 2.5-25.0 μm waveband. A novel simulation code or non-spherical particle aggregation (NSPA) model is applied to build realistic spatial structure models of bioparticle aggregates with different monomer shapes. To eliminate the influence of spatial structure density, we select the bioparticle aggregates with the same porosity of 0.840 to obtain the extinction characteristics. The discrete dipole approximation (DDA) method is adopted to calculate average mass extinction coefficient
According to the calculation results, the influence of the monomer size, monomer number, CRI, and aspect ratio (AR) on the absorption and scattering effects of bioparticle aggregates with different monomer shapes is investigated. The results show that the closer size of bioparticle aggregates to the wavelength of incident light leads to stronger scattering of incident light by bioparticle aggregates. For bioparticle materials with monomer particle sizes ranging from 0.5 to 3.0 μm, the extinction ability in the 3-5 μm waveband is significantly stronger than that in the 8-14 μm waveband (Figs. 6 and 7). When the monomer diameter is 2.0 μm, the
We construct bioparticle aggregates with five typical monomer shapes and calculate and compare the extinction characteristic parameters of them under the influence of multiple factors. The results indicate that there are great differences in the extinction characteristics of bioparticle aggregates with different monomer shapes, which is mainly caused by the differences in light scattering. Meanwhile, generally the more deviation of the monomer shape from the sphere causes greater differences in extinction characteristic of bioparticle aggregates, but the specific magnitude of the relative deviation of the extinction characteristic parameters is the coupling result of various factors such as monomer size, monomer number, and CRI. Our study is of significance for accurately evaluating and optimizing the extinction performance of biological particle materials.
Get Citation
Copy Citation Text
Guolong Chen, Youlin Gu, Yihua Hu, Fanhao Meng, Xi Zhang. Difference in Extinction Characteristics of Bioparticle Aggregates with Different Monomer Shapes[J]. Acta Optica Sinica, 2024, 44(3): 0316001
Category: Materials
Received: Oct. 13, 2023
Accepted: Nov. 20, 2023
Published Online: Feb. 29, 2024
The Author Email: Gu Youlin (ylgu0912@163.com)
