High Power Laser and Particle Beams, Volume. 36, Issue 4, 043013(2024)

PIN diode temperature characteristics prediction based on variational mode decomposition and autoencoder

Yang Zhang, Yang Zhou, Zehai Zhang, Fuxiang Yang, and Xingjun Ge
Author Affiliations
  • College of Advanced Interdisciplinary Studies, National University of Defense Technology, Changsha 410073, China
  • show less

    PIN diodes are critical devices for preventing damage from strong electromagnetic signals. Accurately predicting the temperature rise curve of the PIN diode has important guiding significance for selecting protective devices. Machine learning-based methods can effectively predict the characteristics of devices. However, the temperature rise characteristic curve of the PIN diode contains strong nonlinearity and small fluctuations, and traditional machine learning methods cannot predict accurately. To accurately predict the temperature rise characteristic curve of PIN diodes, this paper proposes a prediction method that combines variational mode decomposition (VMD) and autoencoder to decompose the temperature rise characteristics into sub-signals, which include high-frequency fluctuations, intermediate quantities, and low-frequency trend quantities. Then an autoencoder is used to predict each component. Finally, the predicted values of the components are added together, so as to accurately predict the temperature rise characteristic curve of the PIN diode. By comparing with various machine learning methods, it is verified that combining VMD decomposition can effectively improve prediction accuracy, and the advantage of autoencoder in fitting characteristic curves is also verified.

    Tools

    Get Citation

    Copy Citation Text

    Yang Zhang, Yang Zhou, Zehai Zhang, Fuxiang Yang, Xingjun Ge. PIN diode temperature characteristics prediction based on variational mode decomposition and autoencoder[J]. High Power Laser and Particle Beams, 2024, 36(4): 043013

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jul. 28, 2023

    Accepted: Sep. 28, 2023

    Published Online: Apr. 22, 2024

    The Author Email:

    DOI:10.11884/HPLPB202436.230237
