Spacecraft Recovery & Remote Sensing, Volume. 45, Issue 4, 18(2024)

Planform Geometry Effect on Aerodynamic Performance of Parafoils

Ziyue CHEN1,2, Bowen QIU1,2, Yanjun LI1,2, and Li YU1,2、*
Author Affiliations
  • 1Key Laboratory of Aircraft Environment Control and Life Support, Ministry of Industry and Information Technology, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
  • 2College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
  • show less

    To study the aerodynamic performance of the parafoils with different platform geometries, this paper establishes numerical model of steady flow around parafoils during its glide phase. The influence of the trailing edge shape of parafoil on the flow field structure and aerodynamic characteristics under steady descent is analyzed, and the influence of the trailing edge swept forward angle on the aerodynamic performance is investigated on the basis of this study. The results reveal the following conclusions: the swept-forward parafoil has a reduced pressure at the leading edge of the upper surface, which is conducive to the reduction of drag coefficient due to pressure difference and the best aerodynamic performance, so that trailing edge with forward-swept shape is preferred for parafoil design. With the increase of swept angle, both the lift and drag coefficient decrease first and then increases, and the lift drag ratio increases first and then decreases. The flow separation increases with the swept angle, which leads to increased drag due to pressure difference, as a result, the lift drag ratio decreases. Considering the flow field structure and aerodynamic characteristics, the forward-swept platform shape with swept angle 6° can improve the aerodynamic performance best. This paper can provide some reference for the design of high gliding parafoils.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Ziyue CHEN, Bowen QIU, Yanjun LI, Li YU. Planform Geometry Effect on Aerodynamic Performance of Parafoils[J]. Spacecraft Recovery & Remote Sensing, 2024, 45(4): 18

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Nov. 6, 2023

    Accepted: --

    Published Online: Nov. 1, 2024

    The Author Email: YU Li (yuli_happy@163.com)

    DOI:10.3969/j.issn.1009-8518.2024.04.003
