Journal of Advanced Dielectrics, Volume. 14, Issue 4, 2340008(2024)

Enhanced piezoelectric properties in low-temperature sintered Pb(Zr,Ti)O3-based ceramics via Yb2O3 doping

Wanfeng Zhuang... Weiling Wang, Yaxia Luo, Hong Liu* and Jianguo Zhu |Show fewer author(s)
Author Affiliations
  • College of Materials Science and Engineering, Sichuan University, Chengdu 610065 P. R. China
  • show less

    Pb(Mg0.5W0.5)O3–Pb(Ni13Nb23)O3–Pb(Zr0.5Ti0.5)O3 (PNN–PMW–PZT) piezoceramics were sintered at a low temperature of 900°C by the mixed metal oxide powder solid-state reaction route. CaCO3 and Li2CO3 as sintering aids and Yb2O3 as a dopant were added into the PNN–PMW–PZT ceramic system for low-temperature sintering and enhancement of electrical properties, respectively. The effects of different Yb2O3 doping amounts on the microstructure, dielectric, piezoelectric and ferroelectric properties of the samples were systematically investigated. The piezoceramics doped with 0.1mol% Yb2O3 have optimal electrical properties (d33=563pC/N, kp=0.66, εr=2728 (1kHz), tanδ=0.0176 (1kHz), and TC=301°C). While the piezoceramics doped with 0.3mol% Yb2O3 have optimal energy conversion properties: the piezoelectric voltage coefficient g33=26.7×10?3Vm/N and the effective piezoelectric energy conversion coefficient d33×g33=14366×10?15m2/N.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Wanfeng Zhuang, Weiling Wang, Yaxia Luo, Hong Liu, Jianguo Zhu. Enhanced piezoelectric properties in low-temperature sintered Pb(Zr,Ti)O3-based ceramics via Yb2O3 doping[J]. Journal of Advanced Dielectrics, 2024, 14(4): 2340008

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Research Articles

    Received: Oct. 1, 2023

    Accepted: Dec. 4, 2023

    Published Online: Nov. 5, 2024

    The Author Email: Liu Hong (liuh@scu.edu.cn)

    DOI:10.1142/S2010135X23400088
