Laser & Optoelectronics Progress, Volume. 61, Issue 8, 0811003(2024)

High-Resolution Ptychography Method to Solve the Limitation Problem of Numerical Aperture and Pixel Size

Jingyi Zhang1, Zihao Pei1, Youyou Hu1, Zhongming Yang2, and Jiantai Dou1、*
Author Affiliations
  • 1College of Science, Jiangsu University of Science and Technology, Zhenjiang 212100, Jiangsu, China
  • 2School of Information Science and Engineering, Shandong University, Qingdao 266237, Shandong, China
  • show less

    Imaging resolution of the ptychography is limited by the numerical aperture and CCD (charge coupled device) pixel size. When the CCD target surface is limited, the numerical aperture is limited, and the high-frequency information of the edge of the CCD target surface is easy to miss under the condition that the collected spot is large. In addition, the larger pixel size leads to insufficient sampling rate during imaging, and some detailed high-frequency information will be lost. We propose a high-resolution ptychography method, which can simultaneously solve the resolution problem limited by the numerical aperture and CCD pixel size. First, the extrapolation method is used to supplement the higher-order diffraction information lost due to the limited numerical aperture, and the image reconstructed by the extrapolation method is substituted into the generative adversarial network based on the multi-weight loss function, which can quickly solve the problem of pixel size limitation and improve the imaging resolution. The multi-weight loss function is the weighted sum of mean square error, feature map error and adversarial error. By setting reasonable weights, the pixel and visual level can be balanced. The simulation and experimental results show that this method has a significant effect on improving the resolution of the ptychography and has high computational efficiency.

    Tools

    Get Citation

    Copy Citation Text

    Jingyi Zhang, Zihao Pei, Youyou Hu, Zhongming Yang, Jiantai Dou. High-Resolution Ptychography Method to Solve the Limitation Problem of Numerical Aperture and Pixel Size[J]. Laser & Optoelectronics Progress, 2024, 61(8): 0811003

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Imaging Systems

    Received: Jun. 2, 2023

    Accepted: Jul. 24, 2023

    Published Online: Mar. 1, 2024

    The Author Email: Dou Jiantai (jiantai.dou@just.edu.cn)

    DOI:10.3788/LOP231439
