Journal of Infrared and Millimeter Waves, Volume. 43, Issue 6, 768(2024)

75~110 GHz wideband frequency tripler chip based on planar schottky diode

Yan CHEN1... Fan-Zhong MENG1, Hao-Dong XUE1, Ao ZHANG2,* and Jianjun GAO3 |Show fewer author(s)
Author Affiliations
  • 1The 13th Research Institute,China Electronics Technology Group Corporation,Shijiazhuang 050051,China
  • 2School of Microelectronics(School of Integrated Circuits),Nantong University,Nantong,226019,China
  • 3School of Physics and Electronic Science,East China Normal University,Shanghai,200241
  • show less

    Based on the GaAs planar Schottky diode process, a W band wideband frequency tripler MMIC is designed with a reverse parallel diode pair. By combining the finite element method and equivalent circuit method, an accurate equivalent circuit model of the planar Schottky diode is built in the frequency range of 10~280 GHz. The nonlinear harmonic balance tool is utilized to achieve the optimal frequency tripler design in the W band. The measurement results show that the frequency multiplication loss is less than 15 dB under 17 dBm driving power, and efficiency up to 6.7%. The chip size is 0.80 mm×0.65 mm×0.05 mm.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yan CHEN, Fan-Zhong MENG, Hao-Dong XUE, Ao ZHANG, Jianjun GAO. 75~110 GHz wideband frequency tripler chip based on planar schottky diode[J]. Journal of Infrared and Millimeter Waves, 2024, 43(6): 768

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Millimeter Wave and Terahertz Technology

    Received: Mar. 3, 2024

    Accepted: --

    Published Online: Dec. 13, 2024

    The Author Email: ZHANG Ao (aozhang@ntu.edu.cn)

    DOI:10.11972/j.issn.1001-9014.2024.06.007
