Optical Instruments, Volume. 46, Issue 5, 81(2024)

Polarization detection device based on catenary metasurface

Shanhu GAO... Mingzhu XU, Long CHEN and Xiumin GAO* |Show fewer author(s)
Author Affiliations
  • School of Optical-Electrical and Computer Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China
  • show less

    Traditional optical devices cannot meet the requirements of modern optical integration because of their bulky size and sensitivity to linearly polarized light or circularly polarized light. In this paper, based on surface plasmon polaritons (SPPs), a universal polarization analyzer consisting of catenary was designed. The theory of SPPs propagation was derived, and the electric field pattern of catenary and the distribution of electric field intensity in the center of the device were calculated by using the finite difference time domain method. The results show that when light of different polarization states are incident separately, catenary has a variety of electric field patterns. The significantly differentiated electric field distribution in the center of the device can effectively distinguish the polarization states of linearly polarized light, circular polarized light and vector polarized light (radial polarized light and angular polarized light). Therefore, these results are helpful for the research and development of the catenary multifunctional devices.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Shanhu GAO, Mingzhu XU, Long CHEN, Xiumin GAO. Polarization detection device based on catenary metasurface[J]. Optical Instruments, 2024, 46(5): 81

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Apr. 18, 2023

    Accepted: --

    Published Online: Jan. 3, 2025

    The Author Email: GAO Xiumin (gxm@usst.edu.cn)

    DOI:10.3969/j.issn.1005-5630.202304180087
