Experimental study of air layer drag reduction of self-propelled model

Hao WU1...2, Ziye YANG1,2, Jianxin CAO1,2 and Yongpeng OU3 |Show fewer author(s)
Author Affiliations
  • 1Key Laboratory of High Performance Ship Technology, Ministry of Education, Wuhan University of Technology, Wuhan 430063, China
  • 2School of Naval Architecture, Ocean and Energy Power Engineering, Wuhan University of Technology, Wuhan 430063, China
  • 3College of Naval Architecture and Ocean Engineering, Naval University of Engineering, Wuhan 430033, China
  • show less

    Objectives

    This paper explores the effects of air flow rate and sailing angle on the air layer retention and energy efficiency of the bottom groove of a ship, focusing on a large scale model of a bulk carrier.

    Methods

    An air layer drag reduction self-propelled model system and hull cavity scheme are designed, and drag reduction experiments are conducted under open water conditions. The jet drag reduction effect on the model in a positive floating attitude of ship is examined, as well as the impact of a certain trim angle on the speed and shaft power of the model.

    Results

    The results indicate that, when the main engine speed is constant, air injection can significantly improve the speed of model; after stopping the jet, the air layer within the air cavity of the bottom groove can be maintained for a long time, with better drag reduction efficiency when the ship is in an upright state and the trimming is within 0.25 degrees. When the trimming angle is too large, the gas will overflow from both sides of the model head and the air layer will not effectively cover the bottom of the ship, decreasing the efficiency of drag reduction.

    Conclusions

    Several meaningful conclusions are obtained from the above experiments, providing useful references for the engineering application of air layer drag reduction technology on full-formed ships.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Hao WU, Ziye YANG, Jianxin CAO, Yongpeng OU. Experimental study of air layer drag reduction of self-propelled model[J]. Chinese Journal of Ship Research, 2024, 19(5): 43

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Ship Design and Performance

    Received: May. 13, 2023

    Accepted: --

    Published Online: Mar. 14, 2025

    The Author Email:

    DOI:10.19693/j.issn.1673-3185.03360
