Optical Instruments, Volume. 46, Issue 5, 88(2024)

Study on anti-radiation damage effect of MgF2/Lumogen composite films

Ruicheng JIANG1...2, Yanlei LYU1,2, Shijie LIU3, and Chunxian TAO12,* |Show fewer author(s)
Author Affiliations
  • 1School of Optical-Electrical and Computer Engineering, University of Shanghai forScience and Technology, Shanghai 200093, China
  • 2Engineering Research center of Optical Instruments and Systems, Ministry of Education,University of Shanghai for Science and Technology, Shanghai 200093, China
  • 3Heng Mai Optical Precision Machinery (Hangzhou) Co. Ltd., Hangzhou 311421, China)
  • show less

    In order to investigate the characteristics of high-energy radiation damage in MgF2/Lumogen composite films used for vacuum ultraviolet detection, a 300 W high-energy continuous laser with a wavelength of 1064 nm was employed for irradiation. By adjusting the laser power and scanning rate, the energy and duration of laser irradiation on the film were controlled, and measurements were conducted on photoluminescence intensity, fluorescence decay, and transmittance before and after irradiation. The results demonstrate that under laser irradiation with an energy density ranging from 0.58 to 2.94 W/mm2 at a scanning rate between 50 to 10 mm/min, the fluorescence response intensity upon deep ultraviolet excitation at 160 nm decreases by approximately 1% to 61%, while that upon near-ultraviolet excitation at 273 nm decreases by around 1% to 21%. Moreover, there is a decrease in visible light transmittance within the range of wavelengths from 500 to700 nm by about 2% to 3%. Based on the comparison of the radiation damage observed in single-layer Lumogen films as well as heat conduction analysis performed on composite films, it can be concluded that MgF2 film not only possesses anti-radiation damage capability but also exhibits an anti-reflection effect on Lumogen.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Ruicheng JIANG, Yanlei LYU, Shijie LIU, Chunxian TAO. Study on anti-radiation damage effect of MgF2/Lumogen composite films[J]. Optical Instruments, 2024, 46(5): 88

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Nov. 9, 2023

    Accepted: --

    Published Online: Jan. 3, 2025

    The Author Email: TAO Chunxian (tao@usst.edu.cn)

    DOI:10.3969/j.issn.1005-5630.202311090123
