High Power Laser and Particle Beams, Volume. 36, Issue 4, 043022(2024)
Influence of high-power microwave signal on temperature distribution of PIN limiter
A field-circuit co-simulation model of a two-stage PIN limiter was built to explore the influence of high-power microwave signal parameters on the temperature distribution of the limiter. The simulation results indicate that the increase in microwave pulse amplitude or frequency can expand the PIN diode's high-temperature region inside the two-stage PIN limiter towards the P-region. Compared with the frequency, the amplitude of the microwave pulse has a more significant impact on the temperature distribution of the PIN limiter.
Get Citation
Copy Citation Text
Mingxuan Gao, Yang Zhang, Jun Zhang. Influence of high-power microwave signal on temperature distribution of PIN limiter[J]. High Power Laser and Particle Beams, 2024, 36(4): 043022
Category:
Received: Jul. 4, 2023
Accepted: Nov. 23, 2023
Published Online: Apr. 22, 2024
The Author Email: Zhang Yang (16103271g@connect.polyu.hk)
