Journal of Infrared and Millimeter Waves, Volume. 43, Issue 1, 126(2024)

Research on the stress defect detection of infrared material using differential frequency modulation with cascaded dual photoelastic modulators

Ke-Wu LI1,2,3, Shuang WANG2,3、*, Meng-Wei LI2, and Zhi-Bin WANG2,3、*
Author Affiliations
  • 1School of Electrical and Control Engineering,North University of China,Taiyuan 030051,China
  • 2Institute of Frontier Interdisciplinary Sciences,North University of China,Taiyuan 030051,China
  • 3Engineering and Technology Research Center of Shanxi Province for Opto-electric Information and Instrument,Taiyuan 030051,China
  • show less

    In order to achieve the stress defect detection of infrared materials such as Si, Ge, and GaAs, two Photoelastic modulators working at different frequencies are cascaded to form a polarimetry system. The birefringence retardation and fast axis azimuth introduced by the stress defect are loaded into the modulation signals of the polarimetry system. The amplitudes of the fundamental and differential frequency terms were simultaneously obtained by using digital phase-locked technology, and then the two stress parameters are solved. A detailed analysis of the detection principle was conducted and an experimental system was established for verification. The experimental results show that this method has achieved stress defect detection with a standard deviation of 0.31 ° for stress direction angle and 0.72 nm for stress birefringence retardation. The high-speed, high-precision, and high repeatability stress defect detection are realized, and the measurement of stress defect distribution in a Ge samples are demonstrated. An effective method for infrared material quality testing, analysis, and evaluation is proposed.

    Tools

    Get Citation

    Copy Citation Text

    Ke-Wu LI, Shuang WANG, Meng-Wei LI, Zhi-Bin WANG. Research on the stress defect detection of infrared material using differential frequency modulation with cascaded dual photoelastic modulators[J]. Journal of Infrared and Millimeter Waves, 2024, 43(1): 126

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Research Articles

    Received: Aug. 6, 2023

    Accepted: --

    Published Online: Dec. 26, 2023

    The Author Email: WANG Shuang (wangzhibin@nuc.edu.cn), WANG Zhi-Bin (wangzhibin@nuc.edu.cn)

    DOI:10.11972/j.issn.1001-9014.2024.01.017
