Laser & Optoelectronics Progress, Volume. 61, Issue 8, 0809002(2024)

Efficient Encoding Method for Computer-Generated Hologram

chunqi Li1,2,3,4, Qitai Huang1,2,3,4、*, and Jianfeng Ren1,2,3,4
Author Affiliations
  • 1School of Optoelectronic Science and Engineering, Soochow University, Suzhou 215006, Jiangsu , China
  • 2Collaborative Innovation Center of Suzhou Nano Science and Technology, Soochow University, Suzhou 215006, Jiangsu , China
  • 3Key Laboratory of Advanced Optical Manufacturing Technologies of Jiangsu Province, Soochow University, Suzhou 215006, Jiangsu , China
  • 4Key Laboratory of Modern Optical Technologies of Education Ministry of China, Soochow University, Suzhou 215006, Jiangsu , China
  • show less

    A computer-generated hologram (CGH) can be used to detect an aspheric surface with high accuracy. To enhance the encoding efficiency of the CGH, this paper proposes an encoding method for the segmented description of engraved stripes with a circular arc as the primitive, dividing the encoding process into two steps: binary encoding and curve description. The binary encoding employs the Newtonian iteration method to discretize the phase contour dividing line. The curve description combines the dichotomy and the minimum root-mean-square criterion of the residual error. Furthermore, by leveraging the circular arc to encode the discrete points of the engraved stripes, the engraved stripes are obtained. In this paper, the CGH is designed, encoded, and generated for an off-axis aspheric surface. To obtain an encoding accuracy higher than λ/1000, the operation time is only 3 h, the encoded file is only 39 MB, and the etching time is only 40 min. This demonstrates that the proposed method can considerably enhance the encoding efficiency compared with the traditional encoding method. Error analysis suggests that the wavefront root-sum square (RSS) error of the CGH is only 0.00255λ, demonstrating that the proposed encoding method is efficient and feasible.

    Tools

    Get Citation

    Copy Citation Text

    chunqi Li, Qitai Huang, Jianfeng Ren. Efficient Encoding Method for Computer-Generated Hologram[J]. Laser & Optoelectronics Progress, 2024, 61(8): 0809002

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Holography

    Received: Mar. 7, 2023

    Accepted: Apr. 12, 2023

    Published Online: Apr. 16, 2024

    The Author Email: Huang Qitai (huangqitai@suda.edu.cn)

    DOI:10.3788/LOP230788
