Journal of Advanced Dielectrics, Volume. 14, Issue 2, 2340003(2024)

Preparation and improved energy storage capability of nanocomposites utilizing ultrathin 2D HfO2@TiO2 nanosheets

Chao Chen1、*, Chen Guo1, Xiaoyong Wei2, and Pengfei Wang1、**
Author Affiliations
  • 1Xi’an Institute of Optics and Precision Mechanics, Chinese Academy of Sciences (CAS), Xi’an 710119, China
  • 2Electronic Materials Research Laboratory, Key Laboratory of the Ministry of Education and International Center for Dielectric Research, Xi’an Jiaotong University, Xi’an 710049, China
  • show less

    Polymer-based dielectrics play an important role in electrostatic capacitor by their high energy density (Ue) and flexibility. Herein, we designed a simple high Ue polymer-based dielectrics by controlling the morphology and surface modification of inorganic fillers. To decrease the difference in dielectric properties between fillers and matrix of the nanocomposites, HfO2 acting as the buffer layer with high insulation and appropriate permittivity coated onto the surface of TiO2 nanosheets (TiO2 Ns) to form a core–shell structure. The introduction of HfO2@TiO2 nanosheets (HfO2@TiO2 Ns) makes the nanocomposite with higher dielectric permittivity and lower dielectric loss than poly(vinylidene fluoride-co-hexafluoropropylene) (P(VDF-HFP)) matrix. In addition, the HfO2@TiO2 Ns can establish an efficient barrier to limit the space charge conduction, hamper the growing electric trees, and the HfO2 layer with high insulation could hinder the mobility of charge carriers. The breakdown strength (Eb) of nanocomposite is superior to that of polymer matrix. A small addition of 3wt.% HfO2@TiO2 Ns into P(VDF-HFP) matrix can raise the Eb to 480.7MV/m and present a maximum discharged Ue of 13.9J/cm3. This work demonstrates that it is an effective strategy to improve the Ue via designing the structure and surface state of inorganic filler simultaneously.

    Tools

    Get Citation

    Copy Citation Text

    Chao Chen, Chen Guo, Xiaoyong Wei, Pengfei Wang. Preparation and improved energy storage capability of nanocomposites utilizing ultrathin 2D HfO2@TiO2 nanosheets[J]. Journal of Advanced Dielectrics, 2024, 14(2): 2340003

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Research Articles

    Received: Sep. 11, 2023

    Accepted: Oct. 24, 2023

    Published Online: May. 24, 2024

    The Author Email: Chen Chao (chenchao@opt.ac.cn), Wang Pengfei (pfwang@opt.ac.cn)

    DOI:10.1142/S2010135X23400039
