Laser & Optoelectronics Progress, Volume. 61, Issue 16, 1611020(2024)

Robust and Efficient Analysis Method for Camera Pose, Focal Length, and Radial Distortion Estimation under a Minimal Configuration

Yi Zhang1,2, Baoqiong Wang1,2, Yueqiang Zhang1,2、*, Biao Hu1,2, Wenjun Chen1,2, Xiaolin Liu1,2, and Qifeng Yu1,2
Author Affiliations
  • 1Institute of Intelligent Optical Measurement and Detection, Shenzhen University, Shenzhen 518000, Guangdong, China
  • 2College of Physics and Optoelectronic Engineering, Shenzhen University, Shenzhen 518000, Guangdong, China
  • show less

    Camera calibration based on 3D/2D correspondences is of high significance in various applications. Herein, considering 3D/2D correspondences, the perspective-n-points-focal-radial (PnPfr) method aims to estimate the camera pose, focal length, and radial distortion. Therefore, this study proposed a novel solution to its minimal problem, such as the P4Pfr problem. First, four pseudo-depth factors are defined based on the pinhole and radial distortion models. Then, the translation vector is eliminated by decentralizing the 3D points, yielding a robust P4Pfr model. Finally, the rotation matrix is parameterized with respect to this model and solved by rotation constraints. Within this framework, ordinary and planar configurations are handled separately, with the former solved by Gröebner basis and the latter simplified to a six-degree univariate equation. The accuracy, robustness, and efficiency of the proposed algorithm are evaluated using a numerical simulation and dataset. The results reveal that the ordinary solver provides the highest robustness. Moreover, the robustness of the planar solver is comparable to that of the state-of-the-arts applications. Both the two solvers achieve the fastest solving speed to date.

    Tools

    Get Citation

    Copy Citation Text

    Yi Zhang, Baoqiong Wang, Yueqiang Zhang, Biao Hu, Wenjun Chen, Xiaolin Liu, Qifeng Yu. Robust and Efficient Analysis Method for Camera Pose, Focal Length, and Radial Distortion Estimation under a Minimal Configuration[J]. Laser & Optoelectronics Progress, 2024, 61(16): 1611020

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Imaging Systems

    Received: Aug. 14, 2023

    Accepted: Sep. 18, 2023

    Published Online: Jun. 29, 2024

    The Author Email: Zhang Yueqiang (yueqiang.zhang@szu.edu.cn)

    DOI:10.3788/LOP231916
