High Power Laser and Particle Beams, Volume. 36, Issue 4, 043014(2024)

Performance evaluation of the shielding effectiveness testing system for boundary deformation mutual coupling reverberation chambers

Pingping Wang, Erwei Cheng, Xing Zhou, and Yi Zhang
Author Affiliations
  • Shijiazhuang Campus, Army Engineering University of PLA, Shijiazhuang 050003, China
  • show less

    Conducting material shielding effectiveness testing in complex electromagnetic environments of reverberation chambers has become a key technology for accurately evaluating the electromagnetic protection ability of materials. To study the performance of the boundary deformation mutual coupling reverberation chamber shielding effectiveness testing system, experiments were conducted to verify the dynamic range, electric field distribution characteristics, and uncertainty. The results show that: in actual testing, a test result less than 60 dB is considered a reliable test value; the standard deviation of the electric field in both the transmitting and receiving reverberation chambers is less than 3 dB within the testing frequency range, fully meeting the uniformity requirements of the reverberation chamber; especially, the standard deviation of the spatial electric field in the receiving reverberation chamber is all less than 2 dB, and the uniformity is excellent; the expanded uncertainty of the testing system is 5.90 dB, which can be used as a material shielding effectiveness testing platform.

    Tools

    Get Citation

    Copy Citation Text

    Pingping Wang, Erwei Cheng, Xing Zhou, Yi Zhang. Performance evaluation of the shielding effectiveness testing system for boundary deformation mutual coupling reverberation chambers[J]. High Power Laser and Particle Beams, 2024, 36(4): 043014

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jul. 1, 2023

    Accepted: Dec. 19, 2023

    Published Online: Apr. 22, 2024

    The Author Email:

    DOI:10.11884/HPLPB202436.230345
