Optics and Precision Engineering, Volume. 32, Issue 5, 694(2024)

Integrated platform for micro-vibration simulation and active-passive vibration isolation

Chao QIN1...3, Honghai ZHOU1,2,3, Shuai HE1,3, Zhenbang XU1,3,*, and He ZHU1,23 |Show fewer author(s)
Author Affiliations
  • 1Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun30033, China
  • 2University of Chinese Academy of Sciences, Beijing100049, China
  • 3Key Laboratory of On-orbit Manufacturing and Integration for Space Optics System, Chinese Academy of Sciences, Changchun100, China
  • show less

    To meet the stringent micro-vibration experiment requirements for remote sensing satellites on the ground, a comprehensive experimental platform has been developed. This platform integrates micro⁃vibration simulation with both active and passive vibration isolation capabilities. It evaluates the active and passive vibration isolation effectiveness and the micro⁃vibration simulation's impact separately. Passive isolation is achieved through air-floating support, while active isolation employs an active damping technique. A control strategy based on the linear system's frequency response function is utilized for micro-vibration simulation. The results indicate that the platform's first six modal frequencies are below 10 Hz. The passive isolation system effectively reduces ground micro-vibrations within the 10-200 Hz range, and the active isolation system attenuates the vibration isolation system's resonance peak by 14 dB. The micro-vibration simulation can accurately produce single and multi-frequency disturbances that closely mimic actual satellite conditions. During specific spectrum simulation experiments, the maximum amplitude error was 5.90%, which falls within the acceptable error margin. This versatile integrated experimental platform fulfills all the experimental requirements.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Chao QIN, Honghai ZHOU, Shuai HE, Zhenbang XU, He ZHU. Integrated platform for micro-vibration simulation and active-passive vibration isolation[J]. Optics and Precision Engineering, 2024, 32(5): 694

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Aug. 9, 2023

    Accepted: --

    Published Online: Apr. 2, 2024

    The Author Email: XU Zhenbang (xuzhenbang@ciomp.ac.cn)

    DOI:10.37188/OPE.20243205.0694
