Optics and Precision Engineering, Volume. 32, Issue 23, 3424(2024)

Sensitivity improvement of NO gas detection based on mid-infrared TDLAS

Wenjin XING... Runhao LI and Yunfeng BI* |Show fewer author(s)
Author Affiliations
  • School of Electromechanical and Information Engineering, Shandong University, Weihai264200, China
  • show less

    Accurate detection of nitric oxide (NO) is crucial for applications in environmental, biomedical, and other fields. NO demonstrates strong absorption in the mid-infrared wavelength range, enabling high-sensitivity detection using tunable diode laser absorption spectroscopy (TDLAS) with a mid-infrared quantum cascade laser as the light source. This study develops a three-stage thermoelectric cooler (TEC)-based temperature control structure, introduces a concentration inversion model, and enhances detection sensitivity through optimized laser temperature stability and gas concentration inversion. Experimental results reveal rapid stabilization of laser temperature at room temperature with a stability of 0.003 ℃. The proposed model outperforms the 2f/1f model under identical conditions. Utilizing the signal's peak-to-peak value for concentration inversion over a 30 m optical path and with three-stage laser temperature control, the system achieves an NO concentration measurement linearity of 0.997 5 and a detection limit of 37.5×10-9 within a 0-500×10-6 range. By optimizing both laser temperature control and the inversion model, the NO detection sensitivity is improved by two orders of magnitude.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Wenjin XING, Runhao LI, Yunfeng BI. Sensitivity improvement of NO gas detection based on mid-infrared TDLAS[J]. Optics and Precision Engineering, 2024, 32(23): 3424

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jul. 11, 2024

    Accepted: --

    Published Online: Mar. 10, 2025

    The Author Email: BI Yunfeng (byf@sdu.edu.cn)

    DOI:10.37188/OPE.20243223.3424
