Optics and Precision Engineering, Volume. 32, Issue 5, 635(2024)

High-precision angle measurement based on two-dimensional hybrid position encoding

Huining ZHAO1...2,*, Jie WEN1,2, and Haojie XIA12,* |Show fewer author(s)
Author Affiliations
  • 1School of Instrument Science and Opto-electronics Engineering, Hefei University of Technology, Hefei230009, China
  • 2Anhui Province Key Laboratory of Measuring Theory and Precision Instrument, Hefei30009, China
  • show less

    For high-end manufacturing equipment or precision measurement instruments featuring precision rotating shafting, traditional circular grating struggles to negate the impact of eccentricity error on angle measurement accuracy. This paper introduces a highly precise method for measuring rotation angles utilizing two-dimensional hybrid position coding. Initially, the system comprises a two-dimensional hybrid position coding disk, two CCD cameras, and a telecentric lens. This assembly is attached to a precision rotating shaft to capture its rotation angle. Subsequently, an angle measurement model is developed, mathematically verifying that measurement accuracy remains unaffected by installation eccentricity. The method's accuracy is validated using a multi-tooth indexing table, confirming that angle measurement error is confined to within ±1". Furthermore, when applied to assess the angle positioning accuracy of a direct drive turntable, the method achieves an angle positioning error within ±5". Unlike traditional circular grating measurements, this approach eliminates the need to account for the impact of eccentricity error on accuracy, offering robustness and simplicity in application. Thus, it proves effective for detecting angle positioning errors.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Huining ZHAO, Jie WEN, Haojie XIA. High-precision angle measurement based on two-dimensional hybrid position encoding[J]. Optics and Precision Engineering, 2024, 32(5): 635

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Oct. 7, 2023

    Accepted: --

    Published Online: Apr. 2, 2024

    The Author Email: ZHAO Huining (hnzhao@mail.hfut.edu.cn), XIA Haojie (hjxia@hfut.edu.cn)

    DOI:10.37188/OPE.20243205.0635
