Optics and Precision Engineering, Volume. 32, Issue 21, 3127(2024)

Near-infrared ultra-wideband wavelength measurement for fiber laser

Chenhao YU1... Fengping YAN1,*, Dandan YANG1, Pengfei WANG1, Zhongwei TAN1, Wenhua REN1, Ting FENG2,* and Ting LI3 |Show fewer author(s)
Author Affiliations
  • 1School of Electronic and Information Engineering, Beijing Jiaotong University, Beijing00044, China
  • 2Hebei Key Laboratory of Micro-Nano Precision Optical Sensing and Measurement Technology, Northeastern University at Qinhuangdao, Qinhuangdao066004, China
  • 3School of Physical Sciences and Engineering, Beijing Jiaotong University, Beijing100044, China
  • show less

    A miniaturized, high-precision wavelength measurement technology for near-infrared ultra-wideband single-frequency fiber lasers in the 0.8-2.4 μm range is proposed, based on the principle of the Michelson interferometer. The optical components utilized are compatible with the entire near-infrared band (0.8-2.4 μm). A servo motor translation stage with a maximum stroke of 50 mm, combined with a double-folded optical path design, enables an optical path difference four times the horizontal displacement. Signal acquisition and processing are performed using a high-speed acquisition card and a LabVIEW-based upper computer program, achieving miniaturization, high precision, and rapid measurement. A novel sampling number equivalent resolution method is introduced to simplify the wavelength resolution design process, establishing a direct numerical relationship between wavelength resolution and the number of sampling points, while allowing other parameters to be adjusted independently. Wavelength measurement experiments were conducted on five typical single-frequency lasers (0.8, 1.06, 1.55, 1.94, and 2.05 μm), and the results were compared with those obtained using a commercial high-precision wavemeter. The experimental results demonstrate the effectiveness of the proposed method, with a single measurement time of 1.5 s, measurement accuracies of ±1.4, ±1.1, ±1.2, ±1.2, and ±1.3 pm, and a wavelength resolution consistent with the theoretical value of 0.2×10-6. These findings validate the capability of this miniaturized technology to perform high-precision, rapid measurements across the full 0.8-2.4 μm near-infrared spectrum.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Chenhao YU, Fengping YAN, Dandan YANG, Pengfei WANG, Zhongwei TAN, Wenhua REN, Ting FENG, Ting LI. Near-infrared ultra-wideband wavelength measurement for fiber laser[J]. Optics and Precision Engineering, 2024, 32(21): 3127

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jul. 16, 2024

    Accepted: --

    Published Online: Jan. 24, 2025

    The Author Email: YAN Fengping (fpyan@bjtu.edu.cn), FENG Ting (fengting@neuq.edu.cn)

    DOI:10.37188/OPE.20243221.3127
