High Power Laser and Particle Beams, Volume. 36, Issue 5, 055006(2024)

Design of high voltage constant current charging power supply based on LC series resonance

Jinbo Jiang1...2, Lin Xu1, Zheng Luo3, Wen Yang3, Ming Tang3, Yandong Yao1 and Rui Chen1 |Show fewer author(s)
Author Affiliations
  • 1College of Engineering and New Energy, China Three Gorges University, Yichang 443002, China
  • 2Hubei Provincial Engineering Research Center for Power Transmission Line, China Three Gorges University, Yichang 443002, China
  • 3State Grid Enshi Power Supply Company, Enshi 445000, China
  • show less

    LC series resonant high voltage constant current charging power supply can realize high efficiency and fast charging of the capacitor and has an excellent capacity of anti-load short-circuit, hence it has extensive application prospects in high repetition frequency pulsed power systems. The efficiency of the charging power supply is a crucial factor to determine the ability of the system to operate at repetition rate. Improving efficiency is the primary goal of designing high-voltage capacitor charging power supply. According to the working principle of LC series resonant circuit, it is analyzed that the operating mode of power supply, the switching frequency of the inverter bridge and the distribution parameters of the high-frequency transformer are the main ingredients affecting the efficiency. For a DC power supply with a power of 10 kW and an output voltage of 40 kV, the main circuit parameters were calculated and the circuit model was established using Pspice to verify its accuracy. The soft switching technology was used to reduce the switching loss, and the high frequency transformer with smaller distribution parameters was designed to further improve the efficiency. On this basis, the overall structure design of the power supply was completed. Finally, the charging characteristics of the power supply were tested. Experimental tests indicate that the power supply can charge a 0.1 µF capacitor to 39.5 kV within 37 ms, and the charging efficiency of the power supply is 87.1%.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Jinbo Jiang, Lin Xu, Zheng Luo, Wen Yang, Ming Tang, Yandong Yao, Rui Chen. Design of high voltage constant current charging power supply based on LC series resonance[J]. High Power Laser and Particle Beams, 2024, 36(5): 055006

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Sep. 4, 2023

    Accepted: Jan. 13, 2024

    Published Online: May. 16, 2024

    The Author Email:

    DOI:10.11884/HPLPB202436.230295
