Journal of Atmospheric and Environmental Optics, Volume. 19, Issue 4, 456(2024)

Design and experiment of gas cell for mid-infrared differential absorption detection

WANG Yi1,*... LI Shichun1,2, LIU Ruotong1, LIU Jiahui1, and XIN Wenhui12 |Show fewer author(s)
Author Affiliations
  • 1School of Mechanical and Precision Instrument Engineering, Xi'an University of Technology, Xi'an 710048, China
  • 2Shaanxi Collaborative Innovation Center for Modern Equipment Green Manufacturing, Xi'an 710048, China
  • show less

    To address the problem of the detection performance calibration of differential absorption lidar in mid-infrared band, a straight-through gas cell for differential absorption detection in mid-infrared band was designed and constructed to carry out experiments on differential absorption spectroscopy detection of atmospheric benzene. The structural and optical parameters of the gas cell were designed by using a mid-infrared interband cascade laser as the light source and combining the emission beam parameters of the interband cascade laser. Then the transmittance characteristics and sealing performance of the gas cell were tested at 3187.0 nm and 3235.3 nm wavelengths. Finally, differential absorption lidar detection calibration experiments were carried out using benzene as an example. The results showed that the light transmission rate of the gas cell in the test band was greater than 85%, the negative air pressure was reduced by about 13 kPa after 100 h, and the correlation coefficient of the differential absorption spectroscopy detection calibration experiment was 0.995, indicating that the designed gas cell fully meets the calibration requirements of the mid infrared differential absorption lidar.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yi WANG, Shichun LI, Ruotong LIU, Jiahui LIU, Wenhui XIN. Design and experiment of gas cell for mid-infrared differential absorption detection[J]. Journal of Atmospheric and Environmental Optics, 2024, 19(4): 456

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jan. 13, 2023

    Accepted: --

    Published Online: Jan. 8, 2025

    The Author Email:

    DOI:10.3969/j.issn.1673-6141.2024.04.006
